Upper Playfield Parts
Item Part Number
Description
No.
Item Part Number
Description
2 01-12624
Lower Arch Mounting Bracket (2)
No.
3 A-20246
•• 10 Opto P.C.B. wlBrackets
42 A-9415-2
Jet Bumper Coil Assembly
4 A-15849-L -7
Flipper Assembly Complete
A-12030-3
Jet Bumper Leaf Switch Assy.
20-10290-6
Flipper w/Shaft, Yellow
A-12753-2
Lug & Diode Assembly
5 A-20981-2
Flipper Ball Guide Assy, Left
B-9414-3
Jet Bumper Wafer Assy., Red
6 A-17811
Slingshot Kicker Assembly
03-8254-9
Jet Bumper Car, Red
B-9362-L-2
Coil & Bracket Assembly
23-6710-1
Clear Tubing 1"
10-128
Spring
43 A-9415-2
Jet Bumper Coil Assembly
7 A-17801
Kicker Count Switch
A-12030-3
Jet Bumper Leaf Switch Assy.
8 02-4796-26
Standoff
8/32
x 1
5/8"
A-12753-2
Lug & Diode Assembly
9 A-20958
Left Ramp Assembly
B-9414-3
Jet Bumper Wafer Assy., Red
10 A-16713
V Pad Kicker Assembly
03-8254-13
Jet Bumper Cap, Clear
A-20989
Single Opto Assembly
23-6710-1
Clear Tubing 1"
A-21034
Coil & Bracket Assembly
44 12-7344.2
Center Wire Ramp
10-128
Spring
45 A-20961
• Bank Light Assembly
11 A-20965
Ball Guide & Opto Assembly
46 01-14307
Ball Guide
12 A-20896
3 Bank Drop Target Assembly
47 A-20892
3 Bank Drop Target Assembly
13 A-20911
Spin Disk Assembly
48 A-14196
• Shooter Gate Assembly
14 A-20923
Center Loop Assembly
50 04-10417
Ball Guide
15 04-10445.1
Ball Guide
51 A-15849-R-1
Flipper Assembly Complete
17 A-20851
Vari-Target Assembly
20-9264-6
Small Flipper w/Shaft, Yellow
18 04-10434
Ball Guide
52 04-10418
Ball Guide
19 04-10441.1
Ball Guide
53 A-17801
Kicker Count Switch
20 A-20922
Under Playfield Trough Assy.
54 A-H811
Slingshot Kicker Assembly
21 A-20988
• Left Sign Assembly
B-9362-R-3
Coil & Bracket Assembly
22 A-20912
Trough Assembly
10-128
Spring
23 03-9504
Ball Popper Tube
55 A-15802-P
• Level & Holder Assembly
24 A-20882
Diverter Assembly
56 A-20981-1
Flipper Ball Guide Assy, Right
25 12-7330.2
Wire Popper Ramp
57 A-14876-R-6
Flipper Assembly Complete
26 01-14308
Ball Guide
20-10290-6
Flipper w/Shaft, Yellow
27 04-10407
Ball Guide
58 04-10415.1
Ball Guide
28 A-20116
Flap Gate Assembly
59 04-10423
Ball Guide
29 03-8379-9
Lite Hood
60 A-21 022
Shooter Lane Auto Kicker Assy.
30 4700-00070-00 Flat Washer (12)
61 A-19963-3
Outhole Opto Ball Trough Assy.
31 A-20935
Multi-Ball Assembly
32 A-20116-1
Flap Gate Assembly
33 A-20982
• Bracket & Light Assembly
34 01-14313
Ball Guide
35 A-20907
Popper Mtg. Bracket Assembly
A-21 005
Switch & Bracket Assembly
36 A-17838-1
• Stud Plate
NOT SHOWN:
02-4796-42
• Standoff
8/32
x 2 5/8"
A-13204-90003 Bottom Arch Assembly
37 01-14306
Ball Guide
A-17812-4
Cable Mtg. Brkt. Assy. 1"
38 A-9415-2
Jet Bumper Coil Assembly
A-21040
Playfield Plastic Assembly
A-12030-3
Jet Bumper Leaf Switch Assy.
20-6500
1-1/16
Steel Ball (4)
A-12753-2
Lug & Diode Assembly
36-90003
t
Screened Playfield
B-9414-3
Jet Bumper Wafer Assy., Red
03-8254-16
Jet Bumper Car, Yellow
23-6710-1
Clear Tubing 1"
39 A-20895
3 Bank Drop Target Assembly
40 A-20892
3 Bank Drop Target Assembly
• Not Shown
41 A-20944
Right Ramp Assembly
•• Located Under Playfield
2-38
