XI. PARTS LIST
#1187 ROLLING STONES
MISCELLANEOUS
PART NUMBER
Transformer (Domestic or Export)
.
E-122-125
Bulbs, #44
".,',.,"'".".".,
, E-125-22
Fuse, 1 Amp. 3 AG Slow Blow (Playfield Solenoid Protection)
E-133-44
ASSEMBLY COILS
Coin Lockout
, . , , , . , ,
, , , .. , . , , . FO-36-7000
Flipper (2)
,.".,"'".,
AQ-25-500/
34-4500
Knocker
, , , , , , , , ,
,
AR-26-1200
Outhole Kicker , .. , .. ,
,
, .. ,.,'".,
AN·26-1200
Thumper-Bumper (3)
,
".,',.,
.. ,',.".
AN-26-1200
Sling-Shot (2) .. , , . , , , , , , . ,
AO-26-1200
4 Drop Target ,
, .. ,
, .. , .. ,
, , , . , , , , , , . , , , , , , . , , , , , , , NO-26-1900
Single Drop Target
, .. , ,
, ,. , . , , .. , . . . . . .
.
AN-26-1200
Individual Drop Targets (4) .,'."
.. ,.".,
,
, .. ,
,
,.".
CJ-31-2000
Saucer ,
".,
, .. ,
,
,
, , .. , .. , .. , ,
, . . . .. AO-27 -1300
PLAYFIELD PARTS
See Figure II
MODULES
Lamp Driver A5
, .. , ,., ,.,
"
,. AS-2518-23
Display Driver A1 (5 used) .. " , .. . . . . .
.
, .. , .. ,
AS-2518-21
Solenoid Driver/Voltage Regulator A3
, . , , . ,
, , . AS-2518-22
MPU A4
, , . , , , . ,
, . , . , .. ,
,. AS-2962-16
Transformer
&
Rectifier A2 .. ",.,.,
.. ,
,.,.,
AS-2877-1
Rectifier Board (PartofA2)
".,.,
.. ,
"." .. AS-2518-18
Sound
,.,",
,."..............
. .. AS-3022-5
REPAIRS PROCEDURES/AIDS
Module
&
Component Replacement
, , . ,
, . , . , FO.560-1
AID (Assistance in Diagnostics)
Kit, used with FO.560-1 , , , . ,
, ,
, ,
KIT #485-1
MODULE COMPONENTS
SEE MODULE PARTS LIST
MODULE COMPONENT STARTER KITS
(Each Kit contains an assortment of the most needed electronic parts for use in Module repair)
Kit #490-For Rectifier Board (Part of A2)
Kit #503-For MPU Board A4 (Less Memory U1-U6)
Kit #492-For Solenoid Driver/Voltage Regulator A3
Kit #493-For Display Driver A1
Kit #494-For Lamp Driver A5
Kit #559-For Sound A8
20
