#.1187 ROLLING STONES
H
RUBBER PARTS
A R-521-4
2W'Dia.
(4)
B R-S21-3
2" Dia.
(1 )
•
0
C R-521-7
4" Dia.
(1 )
D R-521
3/4"
Dia.
~~l
E R-521-2
1W'Dia.
F R-406-3
Flipper
(2)
G R-243
5/16" Dia.
(10)
o
PANEL TOP PARTS
0
1. Arch Rail
M1774
2. Rail Post
C-907
(2)
3. Rail Post Cap
C-908
(2)
~
4. Bottom Arch
P-5871-73
! '
5. Shooter Gauge
P-6359-39
6. Ball Gate ~l)
A-1475-12
7. 8all Gate R)
A-1475-13
t::J
8. Panel Plastics
A-2890-144
n
9. Plastic Guide
C-935-1
(3)
I.
10. Rollover Wire Assy.
AS-2806
(8)
•....
0
11. Ball Guide
M-121-32
12. Ball Guide
M-121-33
13. Target Assy. (Red)
ASE-2911-3 (5)
0
14. Inline Target Assy.
ASE-2993-4
15. Drop Target Assy.
ASE-3038
0
16. Shadow Box
M-1874
0
17. Rollover Button
C-900
(2)
0
0 0
0
18. Ball Guide Assy.
A-3032-43
0
19. Ball Guide Assy.
A-3032-42
0
0
20. Minipost & Rubber
ASE-2836-1 (2)
21. Minipost
S-2145-1
(3)
22. Scoring Post Assy.
A-3834
(2)
23. Ball Guide
M-121-93
0
0
24. Ball Guide
M-121-78
L
25. 8all Guide
M-121-79
~II
26. Fli~per & Shaft Assy.
ASE-2214-21 (2~
Lih.
27. Bu fer Wire
M-121-53
(2
i(,
r-'·
~
28. Outhole Wire Assy.
ASE-2806-21
29. Thumper Bumper Cap A-3713-60
(3)
