Power Driver Board Continued ...
J133-1 Red-Brown, lamp row 1 to playfield
J 133-2 Red-Black, lamp row 2 to playfield
J133-3 Key
J133-4 Red-Orange, lamp row 3 to playfield
J 133-5 Red-Yellow, lamp row 4 to playfield
J133-6 Red-Green, lamp row 5 to playfield
J133-7 Red-Blue, lamp row 6 to playfield
J133-8 Red-Violet, lamp row 7 to playfield
J133-9 Red-Gray, lamp row 8 to playfield
J134-Not Used
J135-1
N/C
J135-2
N/C
J135-3 Key
J135-4
N/C
J135-5 N/C
J135-6 N/C
J 135-7 Red-Blue, lamp row 6 to cabinet
J135-8 Red-Violet, lamp row 7 to cabinet
J135-9 Red-Gray, lamp row 8 to cabinet
J136-1 Key
J136-2 N/C
J136·3 Yellow-Gray, lamp column 8 to cabinet
J137- Not Used
J138·1 Yellow-Brown, lamp column 1 to playfield
J138-2 Yellow-Red, lamp column 2 to playfield
J138-3 Yellow-Orange, lamp column 3 to playfield
J138-4 Yellow-Black, lamp column 4 to playfield
J138·5 Yellow-Green, lamp column 5 to playfield
J138-6 Yellow-Blue, lamp column 6 to playfield
J138-7 Yellow-Violet, lamp column 7 to playfield
J138-8 Key
J138-9 Yellow-Gray, lamp column 8 to playfield
3-38
