Playfield Parts
Item Part No.
Description
1 12-6696
Kicker Wireform Upper
2 B-10732-L Ballgate Assembly, Left
3 A-5844-35 Rollover Wire
&
Bracket
4 12-6698
Jet Bumper Wireform, Left
5 C-11144
Right
(J)
Ramp Assembly
6 02-3408
Playfield Post
7 12-6697
Jet Bumper Wireform, Right
8 A-5844-35 Rollover Wire
&
Bracket
9 B-10732-R Ballgate Assembly, Right
10 12-6700
Upper Ball Shooter Wireform
11
R-11145
Ballguide
12 A-10827
Ballgate Assembly
13 C-11134
Lift Ramp Assembly, Left
14 A-10751
BallgateAssembly
15 See Item
#
13
16 C-11133
Lift Ramp Assembly, Right
17 Not Applicable
18 01-6933
Eject Shield
19 A-111 29
Eject Ballguide Assembly
20 12-6695
Lockout Wireform, Left
21 D-9612
Drop Target Assembly
22 01-5224
Ballguide
23 C-11135
Y Ramp Assembly
24 A-111 26
Ballshooter Gate Assembly
25 A-5844-35 Rollover Wireform
&
Bracket
26 A-11124
Y Ramp Sw~chAssembly
27 01-8331
Ball Deflector
28 01-8370
Y Ramp Holding Bracket
29 A-5844-35 Rollover Wireform
&
Bracket
30 A-8108-R Flipper Return Frame
31 C-9952-R Flipper Assembly
32 A-5844-46 Rollover Wireform
&
Bracket
32a A-8645
Wireform
&
Bracket Assembly
32b A-5844-44 Rollover Wireform
&
Bracket
33 12-6468
Anti-rebound Wire
34 C-9952-L
Flipper Assembly
35 A-5844-35 Rollover Wire
&
Bracket
36 A-11125
Flipper Ballguide Assembly, L
37 A-5844-35 Rollover Wire
&
Bracket
37a B-11162
Ballguide
37b A-11128
Ballguide
38 01-8331
Ball Deflector
39 A-11195
Wireform
&
Bracket
40 02-4270
Y Ramp Mounting Post
a) 03-8041
Spacer .250 Large
41 B-11130
Loop Shot Assembly
42 A-11127
Ball Kicker Gate Assembly
43 02-4056
Playfield Post
44 02-4003
Playfield Post
45 A-11252
Eject Ballguide Assembly
46 12-6466-18 Ballguide Wire 4
1/2"
47 12-6699
Wireform
48 01-6933
Eject Shield
49 A-10751
Ball Gate Assembly
