7. Next prepare the backbox. Locate the four mounting bolts and bushings among the parts in the cash
box and set them aside. Cut the tie-wrap that holds the 9-pin serial cable, the 25-pin parallel cable
and the power/speakercable to the wood shipping brace. The shipping brace is held in place by two
screws located on the left and right sides of the backbox. Remove the screws and shipping brace
from the backbox.
8. Stand the backbox upright. Unlock and remove the rear door. Pull the three cables out through the
back door opening and let them hang down the rear of the backbox. See Figure 7.
Backbox Assembly
5OO70·BB
25-PIn ParaDe! Cable to
Power Driver Board
Cabinet Assembly
5OO7O-CAB
Figure 7
9.
With the help of another person, carefully lift the backbox and set it on the cabinet.
10. line up the four mounting holes in the cabinet with the mounting holes in the backbox. Place a
bushing in each of the mounting holes in the cabinet. Fasten the two assemblies together by
inserting a bolt through the backbox and into the cabinet in each of the four mounting holes. See
Figure 8 below.
SECURE BACKBOX TO CABINET WITH
MOUNTING BOLTS AND BUSHINGS.
FigureS
1-4
