Backbox Parts List
Miscellaneous Part List
Part No.
Description
Part No.
Description
A-11-957-2015
Backbox Assembly
A-13204-20 15
Bottom Arch Assembly
A-12497
Upper Hinge Assembly
A-5610-12136
Transfonner 115V /230V
A-12498
Lower Hinge Assembly
A-8550-1
Pot
&
Bracket Assembly
A-12948
3 Lug T/S Resistor Assy
A-8552-20 15
Back Glass Assembly
8-10686-1
Knocker Assembly
B-1 0698-1
Una Voltage Cable Assy
8-12437-1
Speaker Panel Assembly
C-l0843-1
Metal Leg Assembly
5555-12068-00
4" Piezo Speaker 50W C-11026
Une Filter Assembly
5555-12469-00
4.a Round Speaker
C-13155-1
Coin Door 2 slot USA
B-12704
Speaker Grill/Logo Assy
D-11920-16
Mech Panel Assembly
01-8996
Grille Speaker
D-12615
Front Molding Assembly
0.11602-1
Cap
&
Cable Assembly
01-2263-3
Gray Metal Leg
0-11581-2015
Audio Board
01-3493-1
Lock Bracket
D-11883-2015
System 11C CPU Board
01-3527
Latch Plate
0-12246
Power Supply
01-3569-1
Ball Return Runway
0-12247-566
Aux. Power Driver Assy
01-6592
Vent Screen
0-12313-2015
Backbox Interconnect Bd 01-6733
Speaker GriNe
0-13336
PCB Mounting Plate Assy 01-8169
Vent Hole Screen
01-6645
Vent Screen
03-8091
Rear Molding
01-8397
Trunk Latch Bracket
08-7028-T
Playfteld Glass
01-9047
Stop Bracket
08-7377
Leg Adjuster 3.0"
03-8230-3
Glass Retainer
09-17002-26
USA Coin Door
2015-IN
Insert Assembly
09-8803
25¢ Rejector
C-11998-1
Relay Board
20-6500
Steel Ball 1-1/16"
D-12502-1
Bally Right Display
20-6502-A
Plumb Bob
D-12706
Bally Left Display
20-9592-6
'$llow Flipper
01-6655
Insert Latch
24-6549
'44 Bulb
01-9295-1
Holddown Bracket
24-8704
189 Bulb
11-2015-IN
Wood Insert
24-8768
'555 Bulb
20-9504-10
Display Mounting Standoff
24-8802
1906 Bulb
Cable List
Part No.
Description
Part No.
Description
H-l0978
AC Cable
H-13546-2015
Solenoid Cable
H-11834
l8V Rectifier Cable
H-13547-20l5
Insert Cable
H-11835
Knocker Cable
H-13712
Left Ramp Cable
r
H-12l90-2015
Main Backbox Cable
H-13713
X-Ramp Right Cable
H-12l92-2015
Cabinet Cable
H-13714
X-Ramp Left Cable
H-12196-576
Secondary Cable
H-13739
Middle Man Cable
H-12199
Lamp Interconnect Cable H-13740
Flashlamp 1C Cable
H-12200
Switch Interconnect Cable H-13741
Flashlamp 2C Cable
H-12299-2008
Logic/Power Speaker Cbl
H-13742
Flashlamp 3
&
6 Cable
H-12775
Speaker Panel Cable
H-13743
Flashlamp 4C Cable
H-12776
Main Display Cable
H-13744
Flashlamp 7C Cable
H-13544-20 15
Switch Cable
H-13745
Flashlamp 8C Cable
H-13545-2015
Lamp Cable
2·36 Backbox,
Mise
&
Cables
