Relay Board Assembly
0
-em>-
0
pIn
C-11998-1
W1<=:r
'I:
Part No.
Description
W2-c:::::t
I
,
5010-09534-00
Resistor,
on
5S80~9S5S-
01
:JJ
5070-09054-00
Diode, 1N4004, 1.0A
r:
<
5580-09555-01
Relay,DPDT, 24V, 13A
-
5768-12243-00
Bare PCB
-
5791-12273-02
Header, 2 pin Sq.. 156
0
0
5791-12273-07
Header, 7 pin Sq.. 156
Single Lamp Assembly
pIn 8-12224
Radical Lamp Assemb
pIn
C-13578
Part No.
Description
Part No.
Description
24-8768
#555 Bulb, 6.3V
24-8768
#555 Bulb, 6.3V
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
5070-09054-00
Diode, 1N4004, 1.0A
5070-09054-00
Diode, 1N4004, 1.0A
5768-12312-00
Bare PCB
5768-12620-00
Bare PCB
5791-10871-12
Header, Square Flat pin
Lock Lamps Assembly
pIn
C-13577
Snake Lamp Assembly
pIn
C-13749
Part No.
Description
Part No.
Description
24-8768
#555 Bulb, 6.3V
24-8768
#555 Bulb, 6.3 V
24-8767
Twist Lamp Socket
24-8804
V-Wedge PCB Socket
5070-09054-00
Diode, 1N4004, 1.0A
5070-09054-00
Diode, 1N4004, 1.0A
5768-12619-00
Bare PCB
5768-12664-00
Bare PCB
5791-10871-07
Header, Square, Flat pin 5791-10871-08
Header, Square, Flat pin
2 - 34 Lamp
&
Relay Brd
