Connector Identification
RADICAL!
uses WIUlAMS ELECTRONICS GAMES System 11C. The connectors
have an ldentlftcation number. Each plug or jack receives a prefix number (which
ldentlftes the ctrcuit board), followed by a letter ("J" or "P"), and a number. J-
designations refer to the male part of a connector. P-designations refer to the
female part of a connector. For example. 1J 1 designates jack 1 of board 3 (a CPU
Boardjack); 3P6 designates plug 6 of board 3 (a Power Supply Board plug).
Identifying the specific pin number of a connector involves a hyphen, which
separates the pin number from the plug or jack designation. For example, 1J 1-3
refers to pin 3 of jack 1 on board 1.
Other game components may also have similar prefixes preceding their designator
to clarify their locations or related circuit.
Prefix numbers for the System 11C circuit boards and other major assemblies are
Usted below. A prefix number may precede a component designator to identify its
associated unit (e.g.. connector IJ1).
1 - CPU
2 - Master Interconnect
3 - Backbox Power Supply
4 - Score Display
5 - Aux Power Driver
6 -
Backbox
7 - Cabinet
8 - Playfteld
9 - Insert Board
10 - Sound Board
Circuit Boards
System 11C Circuit Boards for
RADICAL!
are in the backbox. They are accessible
by unlocking the Backbox lock. removing the Backbox glass, unlatching the Insert
Board (with lamps and the Digital Display Boards). and swinging it open.
Lamp ctrcuit boards are mounted on the Playfteld.
CPU BOARD
The System 11C CPU Board (pin D-11883-2015) must be equipped with the
ROMs specified in the
RADICAL!
ROM Summary. CPU Board jumpers
WI, W2. W4. W5. W7. Wll. W14. and W16 must be connected.
SOUND BOARD
The Sound Board is pin D-11581-2015.including ROMs and micro-
processor.
SCORE DISPLAY BOARD
RADICAL!
has two Score Display Boards. The BALLYRight Score Display
Board is pin D-12502-1. and the BALLYLeft Score Display Board is pin
D-12706.
