Power'Turn-On and Game Setup
This machine MUST BE PLUGGED INTO A PROPERLY GROUNDED OUTLET to PREVENT SHOCK HAZARD to ensure
PROPER GAME OPERATION. DO NOT use a "cheater" plug to defeat the ground pin on the line cord,
DO NOT cut off the ground pin. The line voltage MUST agree with that specified on the
~ of the cabinet or serious damage to the machine could occur. For low-line applications
(105 or 210V ac), refer to the power wiring diagram.
1. With the coin door closed, plug the game in and turn it ON. The game should come on in
the game over mode as indicated by the player 1 score reading zero, game over lights lit,
and the high score to date alternating with the player scores.
z.
If the game comes on in the diagnostic mode (number of credits display showing 04, ball in
play display showing 00, and player 1 display showing game identification) turn the game
OFF and ON again.
a. If the game now comes on in the game over mode the bookkeeping and game evaluation totals
have been reset to zero.
b. If the game still comes on in the diagnostic mode, open the coin door and turn the game
OFF, and ON twice. This is an indication of the batteries being removed with the power OFF or
coming loose during shipment. This has also resulted in features reverting to factory
settings. Any changes from factory settings must be reentered using procedures provided in the
instruction booklet.
3. If the game still comes on in the diagnostic mode, refer to troubleshooting
procedures in the maintenance manual.
4. Lift plastic at upper right of playfield to insert captive ball, and place two balls on
playfield next to outhole.
J.
Perform diagnostic tests and make any desired changes to features as described in the
instruction booklet.
