GN1E
#1074-E NIGHT RIDER
PARTS LIST
MISCELLANEOUS
Transformer (Domestic or Export)
Bulbs, #44
ASSEMBLY COILS
Chimes
(4)
Coin Lockout
Flipper Left & Right (2)
Knocker
Outhole Kicker
Saucer Eject
Thumper-Bumper (3)
Sling-Shot (2)
PLAYFIELD PARTS
UNIT COILS
Drop Target (Reset)
(4)
NODULES
Lamp Driver AS
Display Driver Al
(S Used)
Solenoid Driver/
Voltage Regulator A3
MPU A4
Transformer & Rectifier A2
Rectifier Board (Part of A2)
"lODULE Cm'1PONENTS
SEE PARTS CATALOGUE
REPAIR. P-qOCEDURES/AIDS
Module Replacement Level
Component Replacement Level
AID (Assistance in Diagnostics)
Kit, used with F.O. 512, F.O. 513
-29-
PART NUHBEH
E-122-125
E-125-22
CN-31-2000
FO-36-7000
AQ-25-S00/
34-5050
AR-26-1200
AN-26-1200
AO-27-1300
AN-26-1200
AN-26-1200
SEE FIGURE II
NO-26-2300
AS-2S1B-14
AS-2513-15
AS-2518-16
AS-2B87-2
AS-2877
AS-2S18-1B
F.O. 512
F.O. 513
KIT #485
