V.
GA~1E
ADJUSTI1ENTS
A. PLAYFICLD PANEL
POST
ADJUSTMENTS:
Posts that control left and right outlane opening on panel
can be moved to make access to out lanes easier or harder for
ball to enter. See Figure II.
Easier entry will decrease playing time and scoring (conservative).
Harder entry will increase playing time and scoring lliberal).
B. BACK BOX GAHE ADJUSTHENTS:
Each game has thirty-two switches located on A4, the
MPU
module, located in the back box, that allow play to be
customized to th~ location. See Figure III. Credits per
coin, maximum credits, credit display, balls per game,
match feature, high game feature, special award and melody
are selectable by means of the switches. The switches are
contained in four-sixteen lead packages numbered 51-8,
S9-l6, S17-24 and s25-32 for easy identification. The
"ON"
toggle position is marked on the assembly. Turn off
power before making adjustments.
~~EQ!~S/COIN ADJUSTMENTS:
The credits given per coin are selectable by means of
switches 1-5 incl., for coin chute #1 and switches 9-13
incl., for coin chute #3. Thirty-one different credit
ratios are available for each coin chute. The switch
settings and resultant credits/coin are listed on page 11 .
Coin Chute #2 is preset to give one game for one coin.
-8-
