T.17 UPIDOWN BANK TEST
This test is used to verify proper operation of the Up/Down Target Bank. It exercises the
Up/Down Bank motor, and the Up/Down Bank position switches.
Upon entry, this test will attempt to position the Frankenstein Table, if necessary. The Up/Down
Bank can only operate with the Frankenstein Table in the UP position. If, at the start of the test,
the Frankenstein Table is unable to be put in its UP position, the message "CAN'T POSITION
FRANK. TABLE" will appear on the bottom line of the display, and the test will not run. It will then
be necessary to fix the FrankensteinTable.
Once the Frankenstein Table has been positioned, the Up/Down Bank test will run automatically.
The test continually moves the Bank to the Up and Down positions, with small pauses when a
new position is reached. To stop the Up/Down Bank motor from moving during. this test, press
the Enter button. To re-start the Up/Down Bank motor, press the Enter button again.
This test is useful for clearing Up/Down Bank UP and Up/Down Bank DOWN switch errors that
may appear in the test report. If the errors exist, they will be shown on the bottom line of the
display. The errors are cleared when the Up/Down Bank completes two consecutive successful
cycles.
During this test, the diagnostic test buttons inside the coin door act as follows:
Escape: This button returns to the previous menu.
Enter: This button toggles the state of the test from Running to Stopped, and from Stopped to
Running.
T.18 FRANKENSTEIN
TABLE
TEST
This test is used to verify proper operation of the Frankenstein Table.
It exercises the
Frankenstein Table motor, and the Frankenstein Table position switches.
Upon entry, this test will attempt to position the Up/Down Target Bank, if necessary. The
Frankenstein Table can only operate with the Up/Down Bank in the DOWN position. If, at the
start of the test, the Up/Down Bank is unable to be put in its DOWN position, the message
"CAN'T POSITION UP/DOWN BANK" will appear on the bottom line of the display, and the test
will not run. It will then be necessary to fix the Up/Down Bank.
Once the Up/Down Bank has been positioned, the Frankenstein Table test will run automatically.
The test continually moves the Table to the Up and Down positions, with small pauses when a
new position is reached. To stop the Frankenstein Table motor from moving during this test,
press the Enter button. To re-start the Frankenstein Table motor, press the Enter button again.
This test is useful for clearing Frankenstein Table UP and Frankenstein Table DOWN switch
errors that may appear in the test report. If the errors exist, they will be shown on the bottom line
of the display. The errors are cleared when the Frankenstein Table completes two consecutive
successful cycles.
During this test, the diagnostic test buttons inside the coin door act as follows:
Escape: This button returns to the previous menu.
Enter: This button toggles the state of the test from Running to Stopped, and from Stopped to
Running.
T.19
DRACULA TEST
This test is used to verify proper operation of the Dracula mechanism. It exercises the Dracula
motor, and the Dracula position switches.
This test has two modes of operation:
1-20
