Power Driver Board Continued. ..
J12S-1 WHT-RED 1SVAC loop from J12S-2.
J12S-2 WHT-RED 1SVAC from transformer secondary.
J12S-3 WHT-RED 1SVAC loop from J12S-4.
J12S-4 WHT-RED 1SVAC from transformer secondary.
J12S-S BlK-YEL 1SVAC loop from J12S-S.
J12S-S BlK-YEl
1SVAC from transformer secondary.
J12S-7 KEY
J12S-S BlK-YEl
1SVAC loop from J12S-9.
J12S-9 BlK-YEl
1SVAC from transformer secondary.
J129-1 RED
9VAC from transformer secondary.
J129-2 RED
9VAC from transformer secondary.
J129-3 KEY
J129-4 BlU-WHT 13VAC from transformer secondary.
J129-S BlU-WHT 13VAC loop from J129-4.
J129-S BlU-WHT 13VAC from transformer secondary.
J129-7 BlU-WHT 13VAC loop from J129-S.
J130
NOT USED
J131
NOT USED
J132
NOT USED
J133-1 NlC
J133-2 RED-BRN +50V to coils.
J133-3 RED-BlK +50V to coils.
J133-4 KEY
J133-5 NlC
J133-S RED-WHT +20V to playlield flashers.
J134--1
NlC
J134--2
Nle
J134--3
Nle
J134-4 KEY
J134--S RED-WHT +20V to insert panel flashers.
J135
NOT USED
J136
NOT USED
J137
NOT USED
J138
NOT USED
J139-1 KEY
J139-2 GRY-VEl
+12V to Coin Door board J2-2.
J139-3 BlK
Ground to Coin Door board J2-1.
J139-4
Nle
J139-S BlK-WHT Signal for coin meter to coin door brd J2-7.
J140-1 KEY
J140-2 GRY-YEl
+Motor EMI Boards
J140-3
Nle
J140-4 NlC
J141-1 KEY
J141-2 GRY-YEl
+12V to 10-0pto board, Auto Adjust Eddy
Sensor boards, Defender Switch board,
and DC Motor Control board
J141-3 BlK
Ground to 10-0pto board, Auto Adjust
Eddy Sensor boards, Defender Switch
board, and DC Motor Control board
J141-4
NlC
3-33
