Defender Switch PCB Assembly
A-21402
(For Dracula Assembly Position Location)
See previous page for circuit diagram.
J1-1 GRY-YEl
From Power Driver board J141-2
J1-2 BlK
From Power Driver board
J
141-3
J1-3 KEY
J1-4 GRN-VIO Switch Col. 7 from CPU board J206-7
J1-5 WHT-YEl
Switch Row 4 from CPU board J208-4
J1-6 WHT-GRN Switch Row 5 from CPU board J208-5
J1-7 WHT-BLU Switch Row 6 from CPU board J208-7
J1-8 WHT-VIO Switch Row 7 from CPU board J208-8
J1-9 WHT-GRY Switch Row 8 from CPU board J208-9
3-24
+12v
GND
Kooy
CC~
RDvl
ROW2
ROW3
ROW"
ROW"
'"
