"HISS 0" OPERATES ~AS 'FOLLOWS:
FOUR TOP TARGFTS,
A ,B ,C AND D, LI'fE CORRESPONDING TOP BtT:MPERS.
LITING
ALL FOUR TOP BUMPERS WILL LITE CENTER HORSESHOE.
BALL GOING THEn CEN-
TER HORSESHOE,
WHEN
LIT,
'.•
1111
ENERGIZE
EX.TRA
BALL RELAY.
TOP 'PARGET
nAif
',"1LL
ALSO LITE
T~'TO
TOP JET BUMPERS FOR 10 SCORING
TOP TARGET
ItDu
WIL,S
ALSO LI'fE
BOTTOM
JET BUMPER FOR 10 SCORING.
THE
15
PLAYFIELD
B~LL LITES ARE
CONTROLLED
BY
ADVANCE
UNIT.
THIS
UNIT
WILL ADVANCE ONE STEP BY HITTING CENT~R TJ..RGET,
WHEN
LIT.
IT
ADVANCES
T'NO STEPS
'NHEN
I
MAKING
TOP
CENTER
OR BOTTOM CENT3R ROLLOVER.
BALL
IN
I
LEFT OR RIGHT EJECT HOLE,
WHEN LIT,
wn.r,
ADVANCE THE UNIT
1,
2~
3
OR
5
STEPS
(DEPENDING ON
THE POSITION
OF
NIThIDER
MATCH UNIT).
t
STEPPING'
UP THE ADV~1'fCE UNIT
1.5
TIMBS 1~lILL LITE LEFT AND RIGHT BOTTOM
ROLLOVERS FOR REPLAY.
pmfSR TRANSFORMER:
LOCATED ON ME~HANISM PANEL,
IT IS EQUIPPED WITH A SECONDARY TAP.
IF
YOUR GAl-IE IS ON LOCATION WITH Ex.TREr1ELY LOW L!NE VOLTAGE,
REMOVE LEAD
FROM LuG
MARKED
24 VOLTS AND SOLDER TO ALTERNATE LUG MARKED "HIGH".
THIS WILL BOOST SECONDARY VOLTAGE APPROXIMATELY 2-3 VOLTS.
LEG
LEVELRRS:
ARE PROVIDED
FOR TWO
PURPOSES - 1st
TO LEVEL GAME ON LOCATION,
2nd TO INCREASE PITCH FOR GAl-iE PERCENTAGING.
IF IT IS DESIRED TO
SPEED UP PLAY AND DECREASE SCORES,
RAISE REAR LEG LEVEI~ERS TO INCREASE
PITCH.
SUGGESTED SCORE
CARDS:
5
BALL
PLAY............
356-1
3
BALL PLAy •••••••.•••
3~6-2
