WPC '95 CPU PCB Assembly
Part Number
A-15814
5048-11033-00
5048-11030-00
5043-09030-00
5048-13375-00
5048-11028-00
5040-14569-00
5048-11031-00
5043-08996-00
5040-13098-00
5645-09025-00
5070-09266-00
5070-08919-00
5700-10176-00
5700-12088-00
5700-08985-00
5700-12424-00
5700-10389-00
5791-10850-00
5791-12516-00
5791-13830-12
5791-13830-09
5791-13830-14
5791-10862-07
5791-13830-13
5671-14516-00
5160-10269-00
5019-09669-00
5010-09358-00
5010-09416-00
5010-09034-00
5010-12104-00
5010-10989-00
5010-09187-00
5010-09534-00
5010-10258-00
5010-09040-00
5281-09867-00
5281-09308-00
5281-09851-00
5315-12031-00
5340-12558-00
5370-12687-00
5281-10182;00
5311-14068-00
5370-12272-00
5284-12651-00
5311-14554-00
5281-09247-00
5520-12084-00
5520-14761-00
A-5400-50059-1
A-5343-50059-1
5880-09022-00
5400-10320-00
5410-12426-00
5162-12422-00
Designator
B1
Cl,C42
C3-C26, C34-C41
C27
C28
C29,C30,C43,C44
C31, C77
C32
C45-C70, C74-C76
C73
DIPSWl
D1, D25
D2-D24, D26, D27
G10A
G11
U4
U9
U20
J201
J211,J202
J205
J206,J207,J209
J208
J210
J212
LED201, LED202, LED203
Q1
RP1
R1, R2, R3, R4, R9, R10, R11,
R23, R24,R25, R26, R43, R44,
R45, R46, R47, R48, R49, R50,
R51, R52, R53, R54, R55, R56,
R57, R58, R59, R60, R61, R62,
R63, R64, R65, R66, R67, R68,
R69, R70, R71, R72, R73, R74,
R75, R76, R77, R78, R79, R80,
R81, R82, R83, R84, R93, R95,
R96, R97, R99, R100, R101,
R102,R103,R104,Rl05,R106
R107, R108, R109, R110, R111,
R112, R113, R114, R117
R5, R6, R7, R8, R12, R13, R87,
R88, R89
R14,R15, R16,R17,R18,R19,
R20, R21, R22, R27, R28, R29,
R30, R31, R32, R33, R34, R35,
R36, R37, R38, R39, R40, R41,
R42,R86, R90,R94,R98
R91
R92
R118, R119, R120, R121, R122
R123, R128, R130
W3,W4, W7, R124, R125
R126
R127
U1, U2
U3
U5
U7
U8
U10
Ul1, U12, U13, U15
U14,U24
U16,U17,U18,
U19,U25, U26
U21
U23
U27
X1
X2
G10
G11
B1
U4
U9
U20
2-8
Description
Battery Holder
Capacitor, .022m,
50v,
10% Axial
Capacitor, 470p,
50v,
Axial
Capacitor, .047m,
50v
(±20%) Axial
Capacitor, 100p,
50v
(10%) Axial
Capacitor, 22p,
50v
Axial
Capacitor, 100ml,
25v
Axial
Capacitor, .001m, 50v, 10% Axial
Capacitor, 0.1 m,
50v
(±20%) Axial
Capacitor, 4.7~F, @35v (±20%)
Switch Dip 8 Pos
Diode 1N5817 1.0A.
Diode 1N4148 150ma
Socket Dip 28.6
Socket Dip 32.6p"
Socket I C 40PI N .6
socket 84 PI N PL CC
Socket I C 18 PIN 3"
26H STR Sq .. 100
34 HDR 2x17 .100
12H STR Sq. Pin .100 Solid Tab
9H STR Sq. Pin .100 Solid Tab
14H STR Sq. Pin .100 Solid Tab
7H STR Sq. Pin .156
13H STR Sq. Pin .100 Solid Tab
LED DSPL RED T-1
3/4
Trans 2N3904 NPN
SIP 1K 9R 105%
Resistor, 1Kn,
1/4w, 5%
Resistor, 470n,
1/4w, 5%
Resistor, 10Kn,
1/4w, 5%
Resistor, 22M,
1/4w, 5%
Resistor, 470Kn,
1/4w, 5%
Resistor, 150n,
1/4w, 5%
Resistor, on, Ow
Resistor, 1M,
1/4w, 5%
Resistor, 33n,
1/4w, 5%
I C 74LS244 OCT BUF
I C 74LS245 TRNC
I C 74LS14 SMTfTRG
I C 74HCT244
IC RAM 8K x8 Static Cmos 100ns
I C MC 34064 Reset CHP
I C 74LS240 UDRVR
I C 74HC574 OCTAL D-Latch
I C LM339 Quad Comp
I C 4584 Hex Schmtt
U I C 74HC237 3 to 8 NON I NV DE
I C 74LS02 Quad Nor
Crystal 32. 768 KHZ
XTL 8MHz Anti-Res Parallel Cut
PIC16C57 Assembly
Game ROM Assembly
Battery 1.5v, AA Alk.
IC MPU 68B09E
IC WPC-89 ASIC
Trans Uln 2803 Oc-Drl
