A-21723
Drawbridge Gate Assembly
This assembly is used in games produced
before July
21, 1997.
Item Part Number
Description
1 04-10774.1
Drawbridge Gate Bracket
2 04-10773.1
Gate-Castle
3 04-10019
Armature Assembly
4 04-10771
Pivot Bracket
5 A-21976
Switch/Bracket Assembly
6 04-10768
Link 2
7 04-10767
Link 1
8 A-21722
Bridge Sub-Assembly
9 01-14674
Linkage
10 03-9219-1
Gear - Cluster
11 04-10886
Gear
&
Shaft Assembly
12 03-9222
Pinion Gear
13 14-8015
Motor - Gear Box
14 20-10131-07Y
Metric Screw, M2.6 x 8
15 4700-00005-00
Flat Washer: 9/64 x 7/16 x 21ga.
16 4004-01003-03
Mach. Screw, 4-40 x 3/16"
17 4008-01157-06
Mach. Screw, 8-32 x 3/8"
18 20-8790
Nyliner Bearing
19 4700-00072-00
Flat Washer, 17/64 x
Y2
x 21 gao
20 20-8712-12
E-Ring, 1/8" Shaft
21 20-8712-25
E-Ring,
14"
Shaft
< :: :
22 A-16908
Opto LED Assembly
23 A-16909
Opto Photo/Transistor Assembly
24 4404-01119-00
Nut 4-40 ESN
25 4010-01196-12
SS 10-32 x
%"
26 10-128
Spring Kicker
27 A-20099
Coil Assembly
28 01-7695-1
Solenoid Bracket
29 03-7067-6
Coil Tubing
30 02-5161
Screw Pin Scoop
31 4008-01083-04
SS 8-32 x
%"
32 H-22011
Opto Cable - Square
33 H-21008-1
Solenoid Cable
34 H-22008-10
2P Reverse Motor Cable
35 4008-01157 -04 Mach. Screw, 8-32x 3/8"
36 03-9823
Spacer
37 01-14746
Z-Bracket
2-34
