AS: LAMP DRIVER MODULE
COMPONENT PARTS LIST
REFERENCE
DESIGNATION
1
2
3
4
5
6
A5
R71-R79
R1-R60, R70
R61-R69
C1
04-07,011-014,018-021,
025-032, 036-039,
043-046, 050-053,
057-060
01-03,08-010,015-017,
022-024, 033-035,
040-042,047-049,
054-056
U1-U4
J1, J3
J4
J2
TP1 , TP2, TP3
ITEM
DESCRIPTION
7
8
9
10
11
12
BALLY
PART
#
AS-2518-23
E-00105-242
E-00105-0237
E-00105-0256
E-00586-0065
E-00585-0014
E-00585-0029
E-00620-0037
E-00715-0004
E-00715-0013
E-00715-0014
P-05399
23
Lamp Driver Module, Complete
Resistor, 20kn, 5%,
V4
W
Resistor, 2kn, 5%,
V4
W
Resistor, 2.2Mn,
V4
W
Capacitor, .01 MFD, 500V
SCR,2N5060
SCR, MCR106-1
I.C., Decoder, 145148
28 Pin Wafer Connector
17 Pin Wafer Connector
23 Pin Wafer Connector
Test Clip
