GAME #1119-E LOST WORLD (FIGURE V)
SOLENOID IDENTIFICATION TABLE
SELF-
TEST
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
02 KNOCKER
03 LEFT SAUCER
04 RIGHT SAUCER
05 LEFT THUMPER BUMPER
06 RIGHT THUMPER BUMPER
SELF-
TEST
#
SOLENOID IDENTIFICATION
07 BOnOM THUMPER BUMPER
08 LEFT SLINGSHOT
09 RIGHT SLINGSHOT
10 COIN LOCKOUT DOOR
11 K1 RELAY (FLIPPER ENABLE)
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
SELF·
TEST
#
SWITCH DESCRIPTION
01 10 PT. RIGHT REBOUND (2)
02 10 PT. LEFT REBOUND (2)
03 RIGHT OUTLANE
04 LEFT OUTLANE
05 TOP R.O. BUnON
&
RT. TOP TAR.
06 CREDIT BUnON
07 TILT (3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN II (MIDDLE)
12
13
14
15
16 SLAM (2)
17 SPINNER
18
19
20
SELF·
TEST
#
SWITCH DESCRIPTION
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
17
DRAGON'S DEN TARGET
LEFT SAUCER
RIGHT SAUCER
RIGHT FLIPPER FEEDER LANE
LEFT FLIPPER FEEDER LANE
"F"TARGET
"E"TARGET
"D"TARGET
"C"TARGET
"B"TARGET
"/X..'
TARGET
RIGHT SLINGSHOT
LEFT SLINGSHOT
BOnOM THUMPER-BUMPER
RIGHT THUMPER-BUMPER
LEFT THUMPER-BUMPER
