GAME #1119-E LOST WORLD (FIGURE V)
SOLENOID IDENTIFICATION TABLE
SELF-
TEST
#
SOLENOID IDENTIFICATION
01 OUTHOLEKICKER
02 KNOCKER
03 LEFTSAUCER
04 RIGHTSAUCER
05 LEFTTHUMPERBUMPER
06 RIGHTTHUMPERBUMPER
SELF-
TEST
#
SOLENOID IDENTIFICATION
07 BOnOM THUMPERBUMPER
08 LEFTSLINGSHOT
09 RIGHTSLINGSHOT
10 COIN LOCKOUTDOOR
11 K1 RELAY(FLIPPERENABLE)
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
SELF-
TEST
#
SWITCH DESCRIPTION
01 10PT.RIGHTREBOUND(2)
02 10PT.LEFTREBOUND(2)
03 RIGHTOUTLANE
04 LEFTOUTLANE
05 TOP R.O. BUnON
&
RT.TOPTAR.
06 CREDITBUnON
07 TILT(3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN II (MIDDLE)
12
13
14
15
16 SLAM(2)
17 SPINNER
18
19
20
SELF-
TEST
#
SWITCH DESCRIPTION
21
22 DRAGON'SDENTARGET
23 LEFTSAUCER
24 RIGHTSAUCER
25 RIGHTFLIPPERFEEDERLANE
26 LEFTFLIPPERFEEDERLANE
27 "F" TARGET
28 "E" TARGET
29 "D" TARGET
30 "C" TARGET
31 "B" TARGET
32 "1\'
TARGET
33
34
35
36 RIGHTSLINGSHOT
37 LEFTSLINGSHOT
38 BOnOM THUMPER-BUMPER
39 RIGHTTHUMPER-BUMPER
40 LEFTTHUMPER-BUMPER
17
