'QUENCE OF OPE~ATION
Rfo!)ET CYCLE
CREDIT UNIT RESET COIL IS ENERGIZED BY SWITCH ON RESET
RELAY
J
THRU SCORE MOTOR INDEX CAM S\UTCH A
J
CREDIT
BUTTON,
Z}t~O SWITCH ON
CREDIT
UNIT,
AND SWITCH ON
GAME-OVER
RELAY OR COIN UNIT LAST POSI-
TION BREAK SWITCH.
END-OF-STROKE
SWITCH ON
CREDIT UNIT RESET
COIL WILL
ENERGIZE
COIN RELAY.
SWITCHES ON COIN RELAY WILL
RUN
SCORE MOTOR, TRIP
GAME-OVER
RELAY, AND ENERGIZE RESET RELAY.
SWITCHES
ON
RESET RELAY WILL OPEN CIRCUITS TO PLA~'IELD
SWITCHES AND OUTHOLE
RELAY.
RUN
SCORE MOTOR, ENERGIZE
RESET
COILS
ON COIN UNIT-BALL COUNT UNIT-PLAYER UNIT AND
GAME OVER RELAY,
PULSE 1
&
2 AND
3
&
4
RESET RELAYS,
AND ENERGIZE BONUS RELAY.
SWITCHES ON 1
&:
2 AND
3
&:
4
RESET RELAYS,
WILL PULSE THE
(16)
SCORING
DRUM
usrrs
UNTIL THb'Y HEAOH ZERO.
SWITCHES ON BONUS RELAY WILL RUN SCORE
MOTOR,
HOLD RESET
RELAY
IN AND PULSE BONUS UNIT RESET COIL,
(BOtlUS RELAY IS H}<~
IN
BY
ZERO SWITCH ON BOUUS UNIT).
WHEN BONUS RELAY DROPS
OUT
J
OUTHOLE RELAY IS ENERGIZBD THRU
ZERO S\>lITCH ON BONUS UNIT AND INDEX CAM SWITCH D.
SWITCHES
OIl
OUTHOLE RELAY WILL RUN SCORE lo10TOR, PULSE BONUS
UNIT S. U. COIL,
AND PULSE BALL RELEASE COIL TO PROPEL BALL TO-
WARD PLUNGER.
