Page 99 - Judge Dredd (Bally)

~~~~----~ -~---~------
A-14525
Kicker 8racket Assembly
Item Part Number ~ription
1. A-6306-2 Bell Armature Assembly
2. A-14526 Mtg. Bracket Assembly
3. 01-8-508-T Solenoid Bracket
4. 10-135 Solenoid Spring
5. 23-6420 Rubber Grommet
6. AE-23-800 Coil Assembly
7. 03-7067-5 Coil Tubing
8. 4008-01017 -04 Mach~ Screw, #8·32 x 1/4"I'·I\I!
9. 03-8523 Insulator
8-10686-1
Knocker Assembly
Item Part Number Description
1. A-5387 Coil Plunger Assembly
2. 01-11273 Mtg. Bracket Assembly
3~ AE-23-800 Coil Sub-Assembly
4~ 01-8-508-T Coil Retaining Bracket
5~ 23-6420 Rubber Grommet
6. 4008-01017-04 Mach. Screw, 8/32 x 1,·1"1'·1{1 I
7. H-11835 Knocker Cable
8. 03-7067-5 Coil Tubing
Judge Dredd 2-31
