U.9 06 Install
5 Ball
U.9 07 Install
3 Ball
Adjustments U.9 06 and U.9 07 can be used to change a game to 3 or
5 ball play, including the changing of certain features to the recommended 3- and 5-ball level.
The Preset Game Adjustments Table for U.S./Canadian Games lists the adjustments and
settings that comprise the individual groups.
Preset Game Adjustments Table for U.S.lCanadian Games
Adjustment
Adjustment
Install 5-Ball
Install 3 Ball
Number
Description
U.9 06
U.9 07
A.201
Extra Ball Percent
15
18
A.204
Count to Start Mode
3
2
A.205
Ball Save Timer
5
5
A.206
Manhunt Timer
25
30
A.207
Sniper Timer
25
30
A.208
Stakeout Timer
25
30
A.209
Pursuit Timer
25
30
A.210
Safecracker Timer
25
30
A.2 11
Impersonator Timer
25
30
A.212
Meltdown Timer
25
30
A.2 13
Battle Tank Timer
25
30
U.9 08 Install
Add-A-Ball
This option deletes all Free Play awards and replaces them
with Extra Ball awards. Individual adjustments are affected, as follows:
Adjustment
Name
A.1 13 Replay Boost
A.1 14 Replay Award
A.1 15 Special Award
A.1 17 Extra Ball Ticket
A.1 19 Match Feature
A4 04 Champion Credits
A.4 05 High Score 1 Credits
A4 06 High Score 2 Credits
A.4 08 High Score
3
Credits
A.4 07 High Score 4 Credits
New Setting
Off
Extra Ball
Extra Ball
No
Off
00
00
00
00
00
U.9 09 Install
Ticket
This option deletes Credit awards and replaces them with Ticket
awards. Individual adjustments are affected, as follows:
Adjustment
Name
A
1 14 Replay Award
A.1 15 Special Award
A.1 16 Match Award
A. 1 17 Extra Ball Ticket
A.1 31 Ticket Expansion Board
A.4 02 H.S.TD. Award
New Setting
Ticket
Ticket
Ticket
Yes
Yes
Ticket
Judge Dredd 1-21
