CPU BOARD
A-12742-20020
J201 Ribbon Cable, Data to J602
J202 Ribbon Cable, Data to J903; JS06; J601
J203 Not Used
J204 Ribbon Cable, Data to J 1, A-161 00
J20S-1 Orange-Brown, Dir Sw 1, Left Coin to J1-14
J20S-2 Orange-Red, Dir Sw 2, Center Coin to J1-13
J20S-3 Orange-Black, Dir Sw 3, Right Coin to J1-12
J20S-4 Orange-Yellow,
Dir Sw 4, 4th Coin J1-17
J205-5 Key
J20S-6 Orange-Green,
Dir Sw S, Escape/Service to J1-11
J205-7 Orange-Blue, Dir Sw 6, DownNolume Down to J1-1 0
J205-8 Orange-Violet, Dir Sw 7, UpNolume Up to J1-9
J20S-9 Orange-Gray, Dir Sw 8, EnterfT est to J1-8
J205-10 Black, Ground to J1-1S
J20S-11 Not Used
J20S-12 Orange-White, Enable toJ1-18
J206 Not Used
J207-1 Green-Brown, Sw Col 1 to Playfield Switches
J207-2 Green-Red, Sw Col 2 to Playfield Switches
J207-3 Green-Orange, Sw Col 3 to Playfield Switches
J207-4 Green-Yellow, Sw Col 4 to Playfield Switches
J207-S Green-Black, Sw Col S to Playfield Switches
J207-6 Green-Blue, Sw Col 6 to Playfield Switches
J207-7 Green-Violet, Sw Col 7 to Playfield Switches
J207-8 Key
J207-9 Green-Gray, Sw Col 8 to Playfield Switches
J208 Not Used
J209-1 White-Brown, Sw Row 1 to Playfield Switches
J209-2 White-Red, Sw Row 2 to Playfield Switches
J209-3 White-Orange, Sw Row 3 to Playfield Switches
J209-4 White-Yellow, Sw Row 4 to Playfield Switches
J209-5 White-Green, Sw Row S to Playfield Switches
J209-6 Key
J209-7 White-Blue, Sw Row 6 to Playfield Switches
J209-8 White-Violet, Sw Row 7 to Playfield Switches
J209-9 White-Gray, Sw Row 8 to Playfield Switches
J210-1 Black, Ground from J114-7
J210-2 Key
J210-3 Black, Ground from J114-S
J210-4 Gray, +SVDC from J114-4
J21 0-5 Gray, +SVDC from J 114-3
J210-6 Gray-Green, + 12VDC from J114-2
J210-7 Gray-Green, +12VDC from J 114-1
o
2 , •••••••••••
=••••
,34 2, ••••••••••••• ,26
0
1 .
I!IDI:UUIOaaOlllll!lCKlDOa
.33 1.
aaaaDCnliDIlOl:laCl
-
25
J202
J201
o
o
J212 J206 J208
~o~oooo~
1*0000000\
loo~oooool
J205
9
J207
9
J209
loottoooooooooliottooooooollooo.oooool
12
1 9
1 9
1
J211 Ribbon Cable, Data from J113
o
J212-1 Green-Brown,
Sw Col 1 to J1-1
J212-2 Green-Red, Sw Col 2 to J1-7
J212-3 Green-Orange,
Sw Col 3 to J 1-7
J212-4 White-Brown, Sw Row 1 to J1-6
J212-S Key
J212-6 White-Red, Sw Row 2 to J1-S
J212-7 White-Orange,
Sw Row 3 to J1-4
J212-8 White-Yellow, Sw Row 4 to J1-3
P,C,Board Legend
J1-J6 COinDoor InterfaceBoard
Jtxx PowerDriVerBoard
J2Xx CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9xx FliptronicII Board
Judge Dredd 3-30
