Unique Parts list
Part Number
Description
Part Number
Description
A-12742-20020
WPC CPU Assembly
A-16943
5-Diode Switch
&
Lamp Assembly
A-13204-20020
Bottom Arch Assembly
A-16947
5-Bank Drop Target Assembly
A-13769-20020
Playfield
&
Insert Assembly
A-16955
Back Panel Assembly
A-16336
Washer
&
Leg Assembly
A-16958
Scoop Assembly
A-16475
Light Assembly
A-16967
Trough Assembly
A-16477
Ring Assembly
A-16968
Trough Assembly
A-16478
Planet Assembly
A-16976-L
Flipper Assembly
A 16482
Opto Assembly, Left
A-16987
Wire Ramp
Assembly
A-16486
5-Bank Opto PCB
A-17038
20020 Unique fJJllS [\,,_;)
A-16569
Metal Ramp Assembly
A-8552-20020
Back Glass Assembly
A-16579
Plastic Ramp Assembly
A-16580
Ball Popper Assembly
C-l0843-BR
Leg Assembly
A-16582
Ball Guide Asssembly
A-16583
Ball Guide Assembly
01-11378-1
Flipper Ball Guide - Left
A-16584
Ball Guide Assembly
01-11378-2
Flipper Ball Guide - Right
A-16585
Ball Guide Assembly
A-16586
Ball Guide Assembly
02-4176-24
M-F Spacer, 8-32 x 1-1/2
A-16587
Ball Guide Assembly
02-4778
M-F Spacer, 8-32
A-16588
Ball Guide Assembly
02-4825-20
M-F Spacer, 8-32 x 1-1/4"
A-16589
Ball Guide Assembly
02-4825-40
M-F Spacer, 8-32 x 2-1/2"
A-16590
Ball Guide Assembly
02-4825-44
M-F Spacer, 8-32 x 2-3/4"
A-16591
Ball Guide Assembly
02-4825-60
M-F Spacer, 8-32 x 3-3/4"
A 16592
Ball Guide Assembly
02-4825-64
M-F Spacer, 8-32 x 4 0"
A 16593
Ball Guide Assembly
02-4826-18
F-F Spacer, 8-32 x 1-1/8"
A 16598
Planet Opto PCB Assy.
02-4826-4
F-F Spacer, 8-32 x 1/4"
A-16630
Plastic Ramp Assembly
02-4827-4
M-M Spacer, 6-32 x 1/4"
A 17231
Plastic Ramp Assembly
A-16650
Switch Button & Cable Assy.
03-8247-7
Double Star Post - Black
A 16769
Arm Lifter Assembly
03-8319-7
Post #8 Starred
A-16775
Bracket Assembly
03-8370-7
Post #8 Black
A-16778
Lifter Assembly
03-8936
Eagle
A 16790
Lamp Assembly, Left
A-16791
Lamp Assembly, Right
11-1111-A
Wood Rail 41-3/4 x 1-1/8 x 1/2"
A-16802
Diverter Assembly
ll-llll-B
Wood Rail 31-3/4 x 1-1/8 x 1/2"
A-16814-1
Cashbox Assembly
11-1112-20020
Wood Cabinet
A-16826
Backbox Assembly
A 16833
Trought Assembly
20-9663-10
Pl,<chButton w/Switch Light
A 16839
14-Lamp Combo Assembly
20-9732-6
Srn._;11Flipper, Yellow
A-16840
1O-Lamp Combo Assembly
A-16841
5-Lamp Combo Assembly
31 -1002-20020
Screened Playfield
A-16843
4-Lamp Board Assembly
31 -1008-20020
Bottom Arch, Silk Screened
A 16844
4-Lamp Board Assembly
31 -1357 -20020
Backglass
A 16891
14-Lamp Combo Assembly
31 -1420-20020
Screened Speaker
Pallel
Cuvel
A 16910-15
Oblong Standup Tgt. (Op, Orange)
31-1788-
Playfield Plastic Set
A-16917 -20020
Sound Board Assembly
31-1793-
Decal Set
A-16928
Speaker /Display Assembly
31-1794-1
Decal
A 16929
4-Lamp Board Assembly
31-1795-
Decal Set
A-16932
Wire Ramp Assembly
31-1797
Screened Plastic Cover
A-16936
Kicker Bracket Assembly
36-20020
Playfield Hard Coat
Judge Dredd 2-35
