Item Part No.
1 12·6468
2 C·11626·L·3
a) 20·9250·5
3 B·12363·L
4 B·12283
a) B-11203-R·1
5 0-12275
6 A-12339
7 A-12208
8 B-11395-1
a) B-11203-R-1
9 A·12209
a) 12-6690
10 12-6466-8
11 C-11223·1
12 0-12297
13 C·11 223-1
14 B-12340
15 0·12205
16 B·11395·1
a) B-9362·R·1
17 A-12160
a) 12·6690
18 12-6466-6
19 B-12001-4
20 A-9465·R
a) 12·6565
21 A-9465·R
a) 12-6565
22 R·12279
23 A-9465-L
a) 12-6565
24 B-12207
25 A-946S-L
a) 12·6565
26 01-8967
27 B-12206
28 B-9361-R·6
a) B-9362-R-1
b) 03-7351-1-9
29 B·12486
30 0-12276
31 B-12451
a) 31-1019-554
b) 12-6780
32 12-6806
33 B·9414-2
a) B-9415-1
34 B-11854-4
35 B-12278
36 C-11223-1
37 B-12363-R
Playfield Parts
Description
Anti-rebound Wire
Lwr Left Flipper Assy
Lg Flipper Paddle
&
Shaft
Left Flipper Return Frame
Kicker Arm ("Sling") Assy
11
Coil & Bracket Assy
Center Ramp Assembly
Ball Guide Assembly
Ball Guide Assembly
BL Lock Kickbig
Coil & Bracket Assy
Ball Gate Assembly
Gate Wire
Wireform, 2"
BL 3-Bank Drop Target
Left Ramp Assembly
TL 3-Bank Drop Target
Ball Guide Assembly
Ball Guide Assembly
TL Kickbig
Coil
&
Bracket Assy
Ball Gate Assembly
Gate Wire
Wireform, 1-1/2"
Standup Target, Red
Ball Gate Assembly
Gate Wire
Ball Gate Assembly
Gate Wire
Upper Mini-Playfield
Ball Gate Assembly
Gate VVire
Ball Guide Assembly
Ball Gate Assembly
Gate Wire
Eject Hole Ball Stop
Ball Guide Assembly
TR Eject Hole
Coil
&
Bracket Assy
Tr Red Plastic Ball Seat
Ramp Deflector Assembly
Right Ramp Assembly
Spinner Gate Assembly
Spinner (no decals)
Switch Wire
Shooter Lane Wireform
Jet Bumper Assy (3)
Bmpr Coil/Bracket Assy
LIFT RAMP Target, Red
Lifting Ramp
BR 3-Bank Drop Target
Right Flipper Return Frame
Item Part No.
Description
38 C-11626-R-3 Lwr Right Flipper Assy
a) 20-9250-5
Flipper Arm on Shaft
39 C-9638-3
Ball Shooter Lane Feeder
Following parts are located under the Bottom Arch:
40 IVa
Bottom Arch Parts
a) B·8623
Upr Trough Baffle Assy
b) C-8235
Lwr Trough Baffle Assy
c) 12-6542
Baffle Wire form
d) 01·3569-1
Ball Trough
e) 01·5575
Bottom Arch Mig Bracket
41 B-8039·2
Outhole Kicker Assy
