BL, BR,
&
TL 3-Bank Drop Target
pin
C-11223-1
Item Part No.
Description
Item Part No.
Description
03-8036
Target, Plain
12 AE-26-1200
Coil Assy
2 B-11224
3-Bank Tgt Sub-Assy
13 01-8413
Bracket Coil Mtg
3 10-364
Spring - Extension
14 A-11389
Plunger & Reset Pit Assy
4 C-11318-1
3-Drop Target Opto Assy
A) 02-3972-1
Plunger
5 20-8712-18
"E" Ring, 3/16" Shaft
8) 01-8408
Reset Plate, 3-Bank
6 20-8712-25
"E" Ring,
1/4"
Shaft
C) 4410-01132-00 Nut, 10-32 ESN
7 10-392
Spring-Compression
15 03-7066-4
Coil Tubing
8 Not Used
16 4700-00016-00 Flat Washer, 3/16 x
7/16
x 17 gao
9 Not Used
17 4008-01016-10 Mach. Screw, 8-32 x
5/8
10 4408-01119-00 Nut, 8-32 ESN
18
4700-00072-00 Flat Washer, 17/64 x
112
x 21 gao
11
A-11397
Stop Bracket Assy
19
23-6626
Rubber Grommet
Item Part No.
Description
Standup Target Assembly
1 8-11854-4
Standup Target (Red)
(Including Diode)
JOKERZ54
.....
