8all Shooter Lane Feeder
C-9638-3
&
Associated Parts
Item Part No.
1 12-6227
2 A-8247
3 10-362
4 A-6949-L
5 A-8050-1
a) 02-3407-2
b) 20-8716-5
c) 03-8085
6 4700-00030-00
7 4700-00103·00
8 A-8268-2
Description
Clip, Hairpin
Eject Cam Assy
Ejector Spring (Plain)
Spring Plate Assy
Coil Plunger Assy
Coil Plunger
Roll Pin
Armature Link
Flat Washer, 17/64 x
112
x 15 ga
Flat Washer, 17/64 x 1/2 x 28
gao
Eject Cam Brkt. Assy
BL & TL Lock Kickbig
pin 8-11395-1
Item Part No.
1 A-5103
a} 02-2364
b) 03-8085
c) 20-8716-5
2 A-5652-1
3 A-11396
4 12-6227
5" 4700-00030-00
• Not Shown
Descrlptlon
Coil Plunger Assy
Coil Plunger
Armature Link
Roll Pin,
1/8
x
7/16
Kicker Crank Assy
Kicker Mounting Assy
Hairpin Clip
Flat Washer, 17/64 x 1/2 x 15 gao
Associated Parts for TL Klckblg
B-9362-R-l
B-7572-1
01-8-508-S
4006·01017-06
4406-01119-00
AE-26-800
03-7066
Coil & Bracket Assy
Brkt. & Stop Assy
Coil Retaining Brkt.
Mach. Screw, 6-32 x 3/8
Nut, 6-32 ESN
Coil Assy
Coil Tubing
Outhole Kicker Assembly
pIn 8-8039-2
Associated Parts
B-9362-R-1
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-23-800
03-7066
Coil & Bracket Assy
Bracket & Stop Assy
Coil Retaining Bracket
Mach. Screw, 6·32 x 3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
3
Associated Parts for BL Kickbig
B-11203-R-1
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-26-1500
03-7066
Coil & Bracket Assy
Brkt. & Stop Assy
Coil Retaining Brkt.
Mach. Screw, 6-32 x
3/8
Nut, 6-32 ESN
Coil Assy
Coil Tubing
Item Part No.
Description
1
A-6378
Mounting Plate Assy
2 A-8335
Coil Plunger Assy
Item Part No.
Description
a) 02-2364
Coil Plunger
b)
20-8716-5 Roll Pin,
1/8
x
7/16
6 AE-23-800
Coil Assy
c) 01-4251
Ball Return Link
7 03-7176-1
Striker Ring
3 03-7066
Coil Tubing
8
10·101·4
Spring-Reset
4 A-6889
Kicker Lever Assy
9
20·8712-25
"E" Ring,
1/4"
Shaft
5
A-8038
Coil Stop Assy
10
4006-01003-03
Mach. Screw, 6-32 x 3/16
JOKERZ51
- -
