Aux Power Driver Unit Board
pin
D-12247-559
Pen No.
Ckl D~slgn8tor
Description
Pen No.
CkI Designator
Description
5763-12184-00
Bare P. C. Board
5580·09555-01 Kl
Relay. DPDT. 13A
5040-09537-00 C1, C3
Capacitor. 100 utd., 100v, Radial
5733-12060-01
Fuse Holden
5040-12181-00 C5. C6
Capacitor, 10 Jlld.. 100v, Radial
5731-08665-00 F4, F5.F6
Fuse, 2A, S·8. 250v
5043-09072-00 C2, C4
Capacitor. 0.1 utd.. 500v
5731-09128-00 Fl, F2A, F3
Fuse.
2-t/2A,
S B. 250v
5010-09160-00 Rl-R8
Resistor, 220~2,
1/4w
C.F, 5% 5731-09651-00 F2C
Fuse, SA. SoB.250v
5012-12238-00 R9
Resistor. 3.3K(2. 5w, 10%
5731-06314-00 F7
Fuse. 4A. SoB.
250v
5010-09534-00 WI, W3, W4, W6 Resistor. 00. 1I4w
5731-09432-00 F8
Fuse, 7A. SoB, 250v
5017-12180-00 VRt, VR2
Varistor,100v
5791-10862-09 J1. J2, J4 - J6, J8 Connector, 9-pin Hdr, Sq Pin
5100-09690-00 BR1, BR2
Bridge Rectifier, 3SA,
200v
5791-10862-07 J3,J7,J9
Connector. 7-pin Hdr, Sq Pin
5070-08785-00 01 - D23
Diode, t N4003
5791-10862-12 J11,J12
Connector, 12-pin Hdr. Sq Pin
5070-09045-00 031 - 046
Diode, MRsoI
5791-10862-04
JIO
Connector. 4-pin Hdr. Sq Pin
5191-12179-00 01- 08
Transistor, TIP36C
Backbox Interconnect Board
pin
D-12313-567
P•••• No.
Ck! Designator
O~"crlptfon
P.rt
No_
5768-12332-00
Master lnterconnectBoard
5791-10862-07
16-8850-222
PCB LO. Label
5791-10862-09
5010-09534-00 Wl-W12
Resistor,
au
5791-10862-10
5012-12238-00 Rt4, R15
Resistor. 3,3K~!. 5w.
10~'D
5791-10862-12
5012-12337-00 Rt3
Resistor. I.5K~l. 5w. 10%
5791-10862-15
5490-10892-00 Ul-U3
Opto Isolator 4N25
5791-10862-16
5731-09651-00 Fl, F2,F3, F4 Fuse. SA.S.B., 250v
5791-10862-18
5733-12060-01 Fl, F2,F3, F4 Fuse Holder
5791-10962-03 J2, J15,J16
Connector, 3-pin Hdr Sq Pin ,156
CkI DesIgnata.
Oegcrlptton
J9
Connector. 7-pin Hdr Sq Pin 156
J6
Connector. 9-pin Hdr Sq Pin 156
J7, JIO. Jt7
Connector. la-pin Hdr Sq Pin 15f)
J5, J13. J18
Connector. 12-pin Hdr Sq Pin 15f)
J9
Connector,IS-pin Hdr Sq Pin .156
J4. Jl1, J12, Jig Connector. IS-pin Hdr ~3qPin lSh
J1, J3, J14
Connector. 18 pin Hrlr. Sq Pin .156
