10
A-20497
Diverter Assembly
2
¥~~
'V ~
t~
,
,
9
,
~
/e
@~.
/////
~
'4 '
->
T ~
/
, ,
/
3
14
Item Part Number Description
Associated Assemblies:
Item Part Number Description
1
2
3
4
5
6
7
8
9
10
11
12
13
04-10245
A-12111
01-7695
20-8790
FL-11753
4008-01003-06
4010-01066-06
4701-00004-00
03-7066-5
A-16636
10-303
A-19293
4010-01169-04
Bracket Assembly
Flipper Stop Bracket Assembly
Solenoid Bracket
Nyliner Bracket
Coil Assembly
Mach. Screw, 8-32 x 3/8"
Mach. Screw, 10-32
x
3/8"
Lock Washer #10 Split
Coil Tubing
Diverter Plunger Assembly
Spring
Drive Arm Assembly
Set Screw, 10-32
x
1/4"
14 04-10248.1
* 15 04-10247
Diverter Assembly #2
Diverter Assembly #1
"Not Shown.
2-22
