Trough IRED LED PCB Assembly
o
OLEDl
o
o
LED3
o
0
PartNumber
Designator Description
5671-12731-00 LED1 - LED5 Infra Red Diode
5791-12622-09 J1
Connector,9-pin HeaderSq.
A-18618-1
Trough IRED Transistor PCB Assembly
o
o
05
o
o
04
o
PartNumber
Designator Description
5163-14114-00 01 - 05
Infra Red PhotoTransistor
5791-12622-09 J1
Connector,9-pin HeaderSq.
2-11
