50042-88
8ackbox Assembly
Ribbon Cables:
Item Part Number
Description
Item Part Number
Description
1 01-6645
Venting Screen
16 5795-12653-03 Ribbon Cable 34-pin, 3"
2
B-1 0686-1
Knocker Assembly
17 5795-13018-01 Ribbon Cable34-pin, 23.5"
3 A-12497
Insert Bd. Hinge Assy., Upper
18 5795-1 0938-15 Ribbon Cable 26-pin, 15"
4 A-14092-6
WPC Mounting Plate Assy.
19 5795-13434-32 Ribbon Cable w/Ferrite 32"
5 A-12498
Insert Bd. Hinge Assy., Lower
6 A-12697-3
Power Driver Assembly
Miscellaneous Parts:
7 A-16917-50042
Sound Board Assembly
8 A-17651-50042
WPC Security CPU Board
A-8552-50042 Tempered Backglass Assy.
9 04-10259
Backbox, Wood
03-8228-2
Glass Channel Top (1)
10 01-9047
Insert Stop Bracket
03-8228-3
Glass Channel Edge (2)
11 A-20442
Speaker/Display Assembly
03-8229-1
Glass Lift Channel (1)
a) 5555-12924-00
Speaker Tweeter, 15w, 40
08-7456
Backbox Glass: 27 x 18-7/8"
b) 5555-12856-00
Speaker, 5-1/4", 25w, 40
20-9718
Wing Screw, 3/8-16 x 2"
c)
5045-12914-00
Capacitor, 10lJfd., 50v(±20%)
31-1357-50042 Screened Translight
d) 5901-12784-00
Dot Matrix Display/Driver Board
12 A-14039.1
Dot Matrix Controller Board
Backbox Cables:
13 A-13379
Lock
&
Plate Assembly
14 50042-IN
Insert Board
H-14584
Dot Matrix Display Power Cable
15 A-15472-1
Fliptronic II Board
H-15476
Logic Power Cable
H-15736-1
Secondary Cable
H-20470
Insert Cable
2-2
