ERROR MESSAGES
The WPC game program has the capability to aid the operator and service personnel. At game
turn-on, or after pressing the Begin Test switch, once the game has been operating for an extended
period, the display may signal with a message, "Press ENTER for Test Report". This indicates the game
program has detected a possible problem with the game.
To obtain details of the problem open the coin door and press the Begin Test switch. Press the
Enter button to begin displaying the message(s). The following messages apply to your game.
Drop Target is Broken
This error occurs when the drop target mechanism fails to set, reset, or the switch is broken.
Left Diverter is Broken
This error occurs when the left diverter mechanism is in the open/closed state and a ball is detected
in the non-diverted path.
Right Dlverter is Broken
This error occurs when the right diverter is in the open/closed state and a ball is detected in the non-
diverted path.
Hand Mechanism Is Broken
This error occurs when the hand mechanism fails and none of the following errors is appropriate.
Hand Mechanism X - No Progress
The X direction motor drive failed to move.
Hand Mechanism Y - No Progress
The Y direction motor failed to move.
Hand Mechanism X Encoder Error
The X direction optical position encoder pair failed, or presented a miss-reading.
Hand Mechanism Y Encoder Error
The Y direction optical position encoder pair failed, or presented a miss-reading.
Hand Mechanism X Home Switch Error
The X direction home switch failed to transition.
Hand Mechanism Y Home Switch Error
The Y direction home switch failed to transition.
Hand Disable by ADJ. A.2 14.
The HAND DISABLED adjustment is set to YES.
Update Sound U2-U8 to N.M. or Later
This game ROM version requires the specified version (N.M.) of sound ROMS (U2-U8).
1-40
