Power Driver Board Continued ...
J135-1
J135-2
J135-3
J135-4
J135-5
J135-6
J135-7
J135-8
J135-9
J136-1
J136-2
J136-3
N/C
N/C
Key
N/C
N/C
N/C
Red-Blue, lamp row
6
to cabinet
Red-Violet, lamp row
7
to cabinet
Red-Gray, lamp row
8
to cabinet
Key
N/C
Yellow-Gray, lamp column
8
to cabinet
J137- Not Used
J138-1
J138-2
J138-3
J138-4
J138-5
J138-6
J138-7
J138-8
J138-9
Yellow-Brown, lamp column 1 to playfield
Yellow-Red, lamp column
2
to playfield
Yellow-Orange, lamp column
3
to playfield
Yellow-Black, lamp column
4
to playfield
Yellow-Green, lamp column
5
to playfield
Yellow-Blue, lamp column
6
to playfield
Yellow-Violet, lamp column 7 to playfield
Key
Yellow-Gray, lamp column 8 to playfield
3-31
