Security CPU Board Assembly
A-17651-50042
~1:::::::::::::::::I~j ~I:::::::::::::I;~
0
J201
o
J202
o
o
m~
o
o
m
- ~
"
a
o
o
I
I
~m~
-
.
o
o
~
I
I
I
I
J212
J20B
J206
1000.0000110.000000011000.000001
B
t
9
1 9
1
J205
J207
J209
to.oooooooool
~.ooooooollooo.oooool
l12
1 9
1 9
1
J201,
26-pin ribbon cable, data to/from J602
J202,
34-pin ribbon cable, data to/from J903; P1; J601
J203- Not Used
J204- Not Used
J205-1 Orange-Brown, ded. sw. row 1, to Coin Door Brd J1-8
J205-2 Orange-Red, ded. sw. row 2, to Coin Door Brd J1-7
J205-3 Orange-Black, ded. sw. row 3, to Coin Door Brd J1-6
J205-4 Orange-Yellow, ded. sw. row 4, to Coin Door Brd J1-5
J205-5 Key
J205-6 Orange-Green, ded. sw. row 5, to Coin Door Brd J1-4
J205-7 Orange-Blue, ded. sw. row 6, to Coin Door Brd J1-3
J205-8 Orange-Violet, ded. sw. row 7, to Coin Door Brd J1-2
J205-9 Orange-Gray, ded. sw. row 8, to Coin Door Brd J1-1
J205-10 Black, ground, to Coin Door Brd J1-10
J205-11 N/C
J205-12 Orange-White, switch enable, to Coin Door Brd J1-11
J206-1 White-Brown, switch row 1, to playfield switches
J206-2 White-Red, switch row 2, to playfield switches
J206-3 White-Orange, switch row 3, to playfield switches
J206-4 White-Yellow, switch row 4, to playfield switches
J206-5 White-Green, switch row 5, to playfield switches
J206-6 Key
J206-7 White-Blue, switch row 6, to playfield switches
J206-8 White-Violet, switch row 7, to playfield switches
J206-9 White-Gray, switch row 8, to playfield switches
J207-1 N/C
J207-2 N/C
J207-3 N/C
J207-4 N/C
J207-5 n/C
J207-6 Green-Blue, switch column 6, to cabinet switches
J207-7 N/C
J207-8 Key
J207-9 N/C
J208-1 Green-Brown, switch column 1, to playfield switches
J208-2 Green-Red, switch column 2, to playfield switches
J208-3 Green-Orange, switch column 3, to playfield switches
J208-4 Green-Yellow, switch column 4, to playfield switches
J208-5 Green-Black, switch column 5, to playfield switches
J208-6 Green-Blue, switch column 6, to playfield switches
J208-7 Green-Violet, switch column 7 to playfield switches
J208-8 Key
J208-9 N/C
J209-1 N/C
J209-2 N/C
J209-3 N/C
J209-4 N/C
J209-5 N/C
J209-6 Key
J209-7 N/C
J209-8 White-Violet, switch row 7, to cabinet switch
J209-9 White-Gray, switch row 8, to cabinet switch
J210-1 Black, ground, from Power Driver Board J114-5,7
J210-2 Key
J210-3 Black, ground, from Power Driver Board J114-5, 7
J210-4 Gray, +5V, from Power Driver Board J114-3, 4
J210-5 Gray, +5V, from Power Driver Board J114-3, 4
J210-6 Gray-Green, +12V, from Power Driver Board J114-1, 2
J210-7 Gray-Green, +12V, from Power Driver Board J114-1, 2
J211,
34-pin ribbon cable, data to/from J113
J212-1 Green-Brown, switch col. 1, to Coin Door Board J3-1
J212-2 Green-Red, switch col. 2, to Coin Door Board J3-2
J212-3 N/C
J212-4 White-Brown, switch row 1, to Coin Door Board J3-3
J212-5 Key
J212-6 White-Red, switch row 2, to Coin Door Board J3-4
J212-7 White-Orange, switch row 3, to Coin Door Board J3-5
J212-8 White-Yellow, switch row 4, to Coin Door Board J3-6
J213-1 Black, to battery holder board J1-1
J213-2 Black, to battery holder board J1-2
J213-3 Key
J213-4 Gray, to battery holder board J1-4
J213-5 Gray, to battery holder board J1-5
J1-1
J1-2
J1-3
J1-4
J1-5
Black, from CPU J213-1
Black, from CPU J213-2
Key
Gray, from CPU J213-4
Gray, from CPU J213-
