Solenoid/Flashlamp Locations
Item Coil/Flasher
Assembly No.
Description
No.
No.
01
AE-26-1500
A-19963
Trough Eiect
02
AE-23-800
A-14525
Autoplunger
03
AE-24-900
A-20498
Popper
04
Not Used
05
AE-25-1000
A-20446
Clear Matrix
06
20-10201
A-20500
Hand Magnet
07
AE-23-800
A-10686-1
Knocker"
08
Not Used
09
AE-26-1200
B-9362-L-2
Left Slingshot
10
AE-26-1200
B-9362-R-3
Right Slingshot
11
AE-26-1200
A-9415-2
Left Jet Bumper
12
AE-26-1200
A-9415-2
Bottom Jet Bumper
13
AE-26-1200
A-9415-2
Right Jet Bumper
14
AE-26-1500
A-20496
Crazy Bob's Eiect
15
AE-26-1200
A-20587
Drop Target Up
16
SMl-26-600
A-20587
Drop Target Down
17
24-8704
A-17803
Jet Flasher
18
24-8802
A-17802
Crazy Bob's Flasher
24-8802
Inset Panel
19
24-8802
Left Slingshot Flasher'
20
24-8802
Right Slingshot Flashr'
24-8802
Insert Panel
21
14-8025
A-20532
'X" Motor Direction
22
14-8025
A-20532
'X' Motor Enable
23
14-8025
A-20532
'Y' Motor Direction
24
14-8025
A-20532
"yo
Motor Enable
25
24-8802
Left Ramp Flasher'
24-8802
Insert Panel
26
24-8802
Right Ramp Flasher'
27
24-8704
04-10280
Hand Popper Flasher
28
24-8802
Right Back Panel Flsr
24-8802
Insert Panel
Flippers
Item Coil/Flasher
Assembly No.
Description
No.
No.
29-30 FL-11629
A-19223-R
Lower Right Flipper
31-32 FL-11629
A-15849-L-2
Lower Left Flipper
33-34
FL-11753
A-20497
Left Diverter
35-36
FL-11753
A-20497
Right Diverter
Gener!!lllIuminatlon
Item Bulb No.
Description
No.
01
24-6549/24-8768
String 1
02
24-6549/24-8768
String 2
03
24-6549/24-8768
String 3
04
24-6549
String 4
05
24-8768
String 5
24-6549
=
#44 BULB
24-8704
=
#89 BULB
./24-8768
=
#555 BULB
24-8802
=
#906 BULB
'USED WITH A-14266-13, RECEPTACLE AND SKIRT.
'\:)
0
'\:)
0
"NOT SHOWN
2-37
