INSTRUCTIONS FOR ALTERING COIN CHUTES
EQUIPPED WITH A FU.P-OVER
DEV~CE.
FOR 1 COIN- FOR 1 PLAY
FIGURE 1
1 CO,iN -
FOR I PLAY (fiGURE
I):
OR 2 COINS- FOR 1 PLAY
FIGURE
1
" X
II
"A"
Wire form
itA"
should be
in positi on
os
shown
in Figure 1, Flip-over lever should
rebound from wire
form "A"
end return to
position
shown
in
Figure 1 everytime a
coin is inserted, All coins pass over the coin trip switch wire "8".
2 COINS -
FOR. I PLAY (FIGURE
2) :
Wire
form
"A"
should be in position ns shown
in
Figure:2 Isee note). Flip-over
lever should clternore from side to side. l st
coin
should' go to cash box without cc-
tucl'ting c:oin trip
switch wire "8", 2nd
coin
should pass the
coin
trip
switch
wire
"B"
and returns
flip-over to
posi tion
as
shown in
Figure 2.
NOTE,
To change frern I coin
play
to
2 coin
ploy
or vice verse - loosen screw "X" and
move screw, bushing
&
wire form "A" to
position
as required - shown
in FI.gure 1
position as required -
shown
in
Figure
I
er Fig.ure
z,
Wlnen using 1
coin
for 11 play, wire form "A" should
not
under
Clnycircum stances
be· allowed to enter the "Banana" slot
and
eeuse
binding
of flip-over lever.
