Power Driver Board
Continued •••
J 133-Not Used
J134-1 Red-Brown, lamp row 1 to playfield
J134-2 Red-Black, lamp row 2 to playfield
J134-3 Key
J134-4 Red-Orange, lamp row 3 to playfield
J134-5 Red-Yellow, lamp row 4 to playfield
J134-6 Red-Green, lamp row 5 to playfield
J134-7 Red-Blue, lamp row 6 to playfield
J134-8 Red-Violet, lamp row 7 to playfield
J134-9 Red-Gray, lamp row 8 to playfield
J135-1 N/C
J135-2 NlC
J135-3 Key
J135-4 NlC
J135-5 NlC
J135-6 NlC
J135-7 Red-Blue, lamp row 6 to cabinet
J135-8 Red-Violet, lamp row 7 to cabinet
J135-9 Red-Gray, lamp row 8 to cabinet
J136-1 Key
J136-2 NlC
J136-3 Yellow-Gray, lamp column 8 to cabinet
J137~ Not Used
J138-1 Yellow-Brown, lamp column 1 to playfield
J138-2 Yellow-Red, lamp column 2 to playfield
~ I
J138-3 Yellow-Orange, lamp column 3 to playfield
f
J138-4 Yellow-Black, lamp column 4 to playfield
J138-5 Yellow-Green, lamp column 5 to playfield
J138-6 Yellow-Blue, lamp column 6 to playfield
J138-7 Yellow-Violet, lamp column 7 to playfield
J138-8 Key
J138-9 Yellow-Gray, lamp column 8 to playfield
3-30
