SWITCH LOCATIONS
Item Switch Part
Description
Item
Switch Part
Description
No.
No.
No.
No.
Fl
SW-1A-194
Lower Right Flipper EOS
27 SW-1A-114
Right Slingshot (Kicker)
F2 A-17316
*Lower Right Flipper Cabinet
SW-1A-120
(Score)
F3 SW-1A-194
Lower Left Flipper EOS
28 A-18019-20
Three Bank Upper
F4 A-17316
*Lower Left Flipper Cabinet
31 A-18019-20
Three Bank Center
F5 SW-1A-194
Upper Right Flipper EOS
32 A-18019-20
Three Bank Lower
F6 A-17316
•. Upper Right Flipper Cabinet
33
Not Used
F7
Not Used
34 A-18019-6
Right Flipper Wrench
F8
Not Used
35 5647-12693-11
left: Ramp Enter
11 20-9663-B-3
Ball Launch
36 5647.12693-11
left Ramp Made
12
Not Used
37 5647-12693-19
left Loop
13 20-9663-1
Start Button
38 5647-12693-19
Right Loop
14 A-15361
"Plumb
Bob Tilt
41 A-18617-1
Top Trough (LED)
15 5647-12693-19
Left Outlane
A-18618-1
(Transistor)
16 5647-12693-19
Left: Flipper Lane
42 A-18617-1
Trough 1 (Right) (LED)
17 5647-12693-19
Right Flipper Lane
A-18618-1
(Transistor)
18 5647-12693-19
Right
Outlane
43 A-18617-1
Trough 2(LED)
21 A-I7238
·SlamTilt
A-18618-1
(Transistor)
22 5643-09288-00
"Coin Door Closed
44 A-18617-1
Trough 3(LED)
23 20-9663-21
Buy-In Button
A-18618-1
(Transistor)
24 5643-09112-00
·Always Closed
45 A-18617-1
Trough 4 (Left) (LED)
25 5647-12693-32
Shooter Lane
A-18618-1
(Transistor)
26 SW-1A-114
Left: Slingshot (Kicker)
46 A-18530-1
Left Ramp Standup
SW-1A-120
(Score)
47 A-18019-6
Turbo Wrench
48 A-18019-6
Jet Bumper Wrench
