PLAYFIELD PARTS
1.
03-8553
Mountain Cover
51.
B-12912-5
Stand Up Target
2.
A-12258-1
Nut Plate
52.
A-14544
Ball Guide
3.
02-4252-22
Stand Off
53.
A-14545
Ball Guide
4.
A-14539
Ball Popper Ramp Assy.
54.
01-10141
Shooter
5.
A-14556
Ball Guide
55.
B-4834-K
Stand Up Switch
6.
12-6986
Ball Guide Wire
56.
31-1002-20003
Screened Playfield
7.
01-10229-2
Ball Deflector Brkt.
57.
A-14540
Wire Ramp Assy
8.
A-14547
Ball Guide
58 B-11203-L-1
Coil & Brkt. Assy.
9.
**A-14595
Isle Mech Assy.
59 B-13921-R
Flipper Ball Guide (2)
10.
A-14651
Isle Lock Mech Assy.
60.
C-13174-R
Flipper mech Assy.
11.
A-14548
Ball Guide
61.
12-6871
Bift Bars 2 3/8"
12.
A-14549
Ball Guide
62.
*03-7960-10003-1 Full Playfield Mylar
13 A-14717
Gilligan Plastic Assy.
63.
*03-7960-20003-2 Jet Bumper Area Mylar
14.
12-6466-26
Ball Guide Wire 61/2"
64.
20003-PLASTICS Set Playfield Plastics
15.
B-14060-10 Stand Up Target (Blue)
65.
Parts below are located beneath Bottom
16.
B-9362-L-2
Coil & Brkt. Assy.
Arch:
17.
B-11304-3
Ramp Lift Assy.
a)
B-8623
Upper Trough Baffle
18.
B-13959
Ball Kicker Assy.
b)
C-8235
Lower Trough Baffle
19.
A-14552
Ramp & Ball Guide Assy.
c)
12-6542
Trough Baffle Wire
20.
B-12583-2
Stand Up Target (Green)
d)
01-3569-1
Ball Trough (runway)
21.
B-12912-16
Stand Up Target (Yellow)
e)
01-5575
Bottom Arch Mtg. Brkt.
22.
A-14541
Wire Ramp Assy.
f)
A-8039-2
Outhole Kicker Assy.
23.
A-14555
Ball Guide
g)
C-9638
Shooter Lane Feeder
24.
B-14060-8
Stand Up Target (Amber)
25.
B-11203-R-1 Coil & Brkt. Assy.
26.
B-12665
Nylon Kicker Assy.
* The Gilligan's Island Hardcoat playfield does not
27.
B-8284-1
Kicker Count Switch
require a protective mylar. However, mylars can
28.
B-12852
Flipper Ball Guide (2)
be purchased thru you local Bally Distributor.
29.
20-9250-6
Flipper & Shaft (Yellow)
30.
C-13174-L
Flipper Mech Assy.
**Upper Island Assy. can be removed for
31.
B-11873
Bottom Arch Kicker Assy.
cleaning playfield by removing set screw on
32.
A-8244-L
Ball Gate Assy.
underside of playfield.
33.
02-4252-26
Stand Off
34.
A-14542
Ball Guide
35.
A-9381-R
Switch & Brkt Assy.
36 B-9361-R-5
Ball Eject Assy.
37.
A-14735
Coil & Brkt. Assy.
38.
03-8222
Eject Spacer
39.
03-7351-1-9 Eject Shield (Red)
40.
A-14543
Ball Guide
41.
A-14546
Ball Guide
42.
A-12842-2
Jumper Bumper Assy.
43.
A-14746
Jumper Bumper Assy.
44.
A-14538
Main Ramp Assy.
45.
02-4252-28
Stand Off
46.
01-10229-1
Ball Deflector Brkt.
47 B-14586
Ball Popper Assy.
48.
A-14707
One Way Ball Gate Assy.
49.
12-6973
Ball Popper Exit Ramp
50.
12-6975
Ball Guide Wire
GILLIGAN'S
ISLAND
2-40
