GILLIGAN'SISLAND 2-18
A-14746 Jumper Bumper Assembly
(See
p.
2-17 for diagram)
Item Part Number
Description
1 AE-26-1200
Coil & Tubing Assy.
a)
50; 0-09054-00
Diode 1N4004, 1.0A.
2
B-12.749
Core Plug & Bracket Assy.
3
17-1112
Thunder Bumper Base, Black
4
01-9166
Switch Plate
5
01-9321
Switch Plate
6
01-9319
Plunger Bracket
7
01-9117
Mounting Bracket
8
02-3406-1
Plunger Coil
9 4705-00002-00
Spring Washer, 1/2"
10 01-9116
Bracket Plate
11 01-9320
Plate, Bakelite
12 10-411
Compression Spring
13 A-14271
Socket Assembly
a)
24-8768
Bulb #555
(6.3v.,
0.25A.)
b)
24-8813
Lamp Socket
14 Not Used
15 Not Used
16 03-8292-7
Body, Black
17 A-12854
Flange & Stud Assembly
18 03-6035-7
Wafer, Black
19 10-326
Compression Spring
20 44011-01119-00
Nut, 8-32 ESN
21 440-3-01119-00
Nut, 6-32 ESN
22 B-13267
Switch & Diode Assembly
a)
SW-1A-187
Switch
b)
5070-06258-00
Diode, 1N4001, 1.0A.
23 4008-01070-14
Mach. Screw, 8-32 x 7/8
24 4005-01016-18B
Mach. Screw, 5-40 x 1-1/8
25 4008-01015-04
Tf,
8-32 x 1/4
26 4008-01015-06
rr,
8-32 x 3/8
27 4108-01001-10
Sh. Metal Screw, #8 x 5/8
*
28 03-7066
Coil Tubing
29 03-8291-9
Thumper Bumper Cap, Red
30 4004-01003-08
Mach. Screw, 4-40 x
112
31 03-6047-16
Tubing
• Not Shown.
