Items for
Left Flipper Assembly
Only.
GILLIGAN'S ISLAND 2-14
C-13174-R
C-13174-L
Item Part Number
1.
B-13104-R
*
B-13104-L
2.
03-7811
3.
RM-21-06
4.
5045-12098-00
5.
4701-00002-00
6.
4105-01019-10
7.
23-6622
8.
4008-01079-05
9.
4701-00003-00
10. 01-9375
11. 03-7520-2
12. 20-6516
13. 4010-01066-06
14. 4701-00004-00
15. A-12111
16. HW-30018-6
17. FL-11630
18. 01-7695
19. 4006-01017-04
20. 10-376
21. B-l0655-R
*
B-l0655-L
a) 02-4179
b) 4010-01086-14
c) 4700-00023-00
d) 4701-00004-00
e) 4410-01132-00
f)
A-l0656"
1.) 02-4219
2.) 20-9370-1
3.) 03-8050-1
g) B-l0657-R
*
B-l0657-L
1.) 01-8073-R
*
01-8073-L
2.) 17-1037
3.) 4010-01066-18
4.) 4410-01127-00
5.) 4700-00107-00
6.) 4701-00004-00
7.) RM-23-06
22. 23-6577
23.
03-7568
24. 4006-01005-06
25. 4406-01117-00
Flipper Assembly (Right)
Flipper Assembly (Left)
Description
Flipper Base Assy, Right
Flipper Base Assy, Left
End of Stroke (EOS) Sw.
Sleeve, Vinyl (Cap. leads)
Capacitor, 2.2 IlFd, 250V, 20%
Lockwasher, #6 Split
Sh. Metal Screw,#5 x 5/8
Tape, Double-sided
Cap Screw, 8-32 x 5/16
Lockwasher, #8 Split
Switch Mounting Bracket
Ty-Wrap, Nylon
Speednut, Tinnerman
Cap Screw, 10-32 x 3/8, SH
Lockwasher, #10 Split
Flipper Stop Assembly
Wire, 18 AWG, Blue
Flipper Coil (Red)
Solenoid Bracket
Mach. Screw, 6-32 x 1/4
Coil Plunger Spring
Crank Link Assembly, Right
Crank Link Assembly, Left
Link Spacer Bushing
Cap Screw, 10-32 x 7/8, SH
Flatwasher, 5/8 x 13/64 x 16ga.
Lockwasher, #10 Split
Nut, 10-32 ESNA
Flipper Link Assembly
Coil Plunger
Spring Pin, 5/32 dia. x 7/16
Flipper Link
Flipper Crank Assy, R.
Flipper Crank Assembly
Flipper Crank, Right
Flipper Crank, Left
Crank Washer
Cap Screw,10-32 x 1-1/8
Nut, 10-32 Hex Head
Flatwasher, 5/8 x 13/64 x 12ga.
Lockwasher, #10 Split
Tubing, H. S. 1/4 DWP
Bumper Plug
Flipper Bushing
Mach. Screw, 6-32 x 3/8
Nut, 6-32 Hex.
