GILLIGAN'S ISLAND 2-10
A·14039 Dot Matrix Controller Assembly
Item Part Number
Ckt Designator
Description
1
5010-08991-00
R1
Resistor, 4.7Kn, 1/4w, 5%
2
5010-09224-00
R10
Resistor, 2700, 1/4w, 5%
3
5010-09534-00
R7
Resistor, 00
4
5010-12832-00
R3, R6, R12, R13
Resistor, 47Kn, 1/2w, 5%
5
5010-12841-0('
R4,R5
Resistor, 1200,
1/2w, 5%
6
5012-12830-00
R9
Resistor, 1.8Kn, 5w, 5%
7
5012-12842-00
R11
Resistor, 1200, 5w, 5%
8
5012-12843-00
R8
Resistor, 4.7K, 5w, 5%
9
5040-08986-00
C3
Capacitor, 1OOllfd., 10v, (±20%)
10 5040-12324-00
C4, C7
Capacitor, 1SOllfd., 160v, (±50%)
11 5043-08980-00
BYPASS
Capacitor, .01Ilfd., SOv, (+80, -20%)
12 5043-09072-00
C6,C9,C10
Capacitor, .tufd., SOOV,(+80, -20%)
13 5043-09845-00
C1, C2, C11
Capacitor, 1KP, SOv, (±20%)
14 5070-09054-00
07
Diode, 1N4oo4, 1.0A.
15 5075-12824-00
06
Zener, 1N4742A, 12v
16 5075-12826-00
03- 05
Zener, 1N4759A, 62v
17 5100-12833-00
BR1, BR2
Bridge, 400v, 1A.
18 5160-10269-00
01
Transistor, 2N3904 NPN
19 5164-09056-00
02, 010
Transistor, MPSD02, NPN
20 5164-12154-00
03,07
Transistor" MJE15030 NPN
21 5194-09055-00
04,05
Transistor, MPSD52 PNP
22 5194-12155-00
06
Transistor, MJE1S031 PNP
23 5281-09738-00
U16, U25 - U27
IC,74LS157
24 5281-10033-00
U3
IC,74LS30
25 5281-10043-00
U31 - U33, U35
IC,74LS175
26 5311-10946-00
U4, U5, U17, U18,
IC,74HC74
U20
27 5311-10947-00
U9
IC,74HC125
28 5311-10951-0l
U10 - U12
IC,74HC161
29 5311-10977-0(,
U6
IC,74HC04
30 5311-12817-00
U29
IC,74HC165
31 5311-12819-00
U21
IC,74HC688
32 5311-12820-00
U23
IC,74HC27
33 5311-12822-00
U13 - U15
IC,74HC193
34 5315-12009-00
U22
IC, 74HCT374
35 5315-12812-00
U1, U2, U30
IC,74HCT138
36 5315-12813-00
U28
IC, 74HCT245
37 5315-12815-00
U8,U34
IC,74HCT08
38 5315-12816-00
U19
IC,74HCT32
39 5315-12821-00
U7
IC, 74HCT240
40 5340-12278-00
U24
SlRAM 2064 1SONS
41 5551-09822-00
L1
IND 4.7IlH, 3.0A.
42 5671-090 19-00
010
Display LED Red
43 5705-09199-00
03,06,07
Heatsink 6030B
44 5731-12328-00
F601,F602
Fuse, 3I8A.,SB, 250v
45 5733-12060-00
Fuse Holder (F601, F602)
46 5760-12710-00
PC Board
47 5791-108SO-00
J602
Connector, 26-pin STR Sq.
48 5791-10862-05
J605
Connector, 5-pin Header Sq.
49 5791-10862-01
J606
Connector, 7-pin Header Sq.
50 5791-10862-08
J604
Connector, 8-pin Header Sq.
51 5791-12516-0)
J601
34 Hen 17x2 STR
52 5791-12827-00
J603
14 Hen 7x2 STR
53 5010-09036-00
R14-R23
Resistor, 1000,
1/4w, 5%
54 20-9229
03,06,
07
Thermal Compound
55 4006-01003-06
03,06,
07
Mach. Screw, 6-32 x
3/8
56 4406-01128-00
03,06,
07
Nut, 6-32 KEPS
57 5043-09492-00
C5,C8
Capacitor, 1OOP, SOv, (±10%)
.
Refer to Schematic #16-9148 .
