GILLIGAN'S ISLAND 1-34
T.ll Display Test
I
Once the test name is shown under the Test Menu, press the Enter button. This Test automatically turns
On and Off every dot in the Dot Matrix Display. A series of patterns appear in sequence. It starts with
one line, turned On, moving across the screen vertically, then horizontally. The screen inverses and
one line, turned Off, moves across the screen vertically, then horizontally. The second pattern is a
series of lines, turned On, moving across the screen diagonally. The screen inverses and there is a
series of lines, turned Off, moving across the screen diagonally. The third pattern is gridlines turned
On, then turned Off. The last pattern is a box forming an outline of dots around the matrix that are
turned On. After the box outline the test repeats itself.
Press the Escape button to return to the Test Menu. Then, either press the Up or Down button to return to a
previous Test, or press the Escape button again to return to the Main Menu. Once in the Main Menu,
press the Up button to move to the next menu selection, the Utilities Menu, or press the Down button to
return to a previous Main Menu selection.
T.12 MotorTest
Once the test name is shown under the Test Menu, press the Enter button. This test allows you to cycle
through the motor operation. There are two modes for testing the motor, Running and Stop.
Running -
The motor will rotate and show the two switches (opto and lock) closing and opening.
There will be a delay of 10 seconds to prevent over heating of the unit, then it will
repeat.
Stop-
Press the Enter button at any time during the Running test mode and the test stops.
Use the Up or Down buttons to cyclethrough each phase of the test manually .
Press the Enter button again to resume the Running test mode.
r
Press the Escape button to return to the Test Menu. Then, either press the Up or Down button to return to a
previous Test, or press the Escape button again to return to the Main Menu. Once in the Main Menu,
press the Up button to move to the next menu selection, the Utilities Menu, or press the Down button to
return to a previous Main Menu selection
