Jumper Charts
Solenoid Table
Wire Connections Solenoid Part Number
Sol. Solenoid Driver Flashlamp Type
No. Function Type Color Trnstr
01 Left Lock High Power Vio-Brn J130-1 082 AE-23-800
02 Island Lock High Power Vio-Red J130-2 080 A-14701
03 Outhole High Power Vio-Orn J130-4 078 AE-26-1200
04 Ball Popper High Power Vio-Yel J130-5 076 AE-26-1200
05 Right Sling High Power Vio-Grn J130-6 064 AE-26-1500
06 Left Sling High Power Vio-Blu J130-7 066 AE-26-1500
07 Knocker High Power Vio-Blk J130-8 068 AE-23-800
08 Kickback High Power Vio-Gry J130-9 070 AE-23-800
09 Island Motor Low Power Brn-Blk J127-1 058 14-7964-1
10 Trough Low Power Brn-Red J127-3 056 AE-26-1200
11 Hold Lock Low Power Brn-Orn J127-4 054 A-14701
12 Island Light Low Power Brn-Yel J127-5 052 24-8802 #906
13 Left Jet Low Power Brn-Grn J127-6 050 AE-26-1200
14 Right Jet Low Power Brn-Blu J127-7 048 AE-26-1200
15 Bottom Jet Low Power Brn-Vio J127-8 046 AE-26-1200
16 Top Eject Low Power Brn-Gry J127-9 044 AE-28-1500
17 Head 1 Flasher Flasher Blk-Brn J125-1 042 #906 P~d,#906 Ins
18 Island Flasher Flasher Blk-Red J126-2 J125-2 040 #89 P~d, #906 Ins
19 Left Bank Flasher Flasher Blk-Orn J126-3 J125-3 038 #89 P~d, #906 Ins
20 Left Flipper Flasher Flasher Blk-Yel J126-4 036 #89 P~d, #906 Ins
21 Right Flipper Flasher Flasher Blu-Grn J126-6 J125-6 028 #89 Plfd, #906 Ins
22 Head 2 Flasher Flasher Blu-Blk J126-7 J125-7 030 #906 P~d,#906 Ins
23 Ramp Up Coil Low Power Blu-Vio J126-8 J12~8 034 AE-26-1200
24 Ramp Down Coil Low Power Blu-Gry J126-9 J125-9 032 SM1-26-600
25 Right Bank Flasher Flasher Blu-Brn J122-1 026 #89 P~d, #906 Ins
26 Treasure Flasher Flasher Blu-Red J122-2 024 #906 P~d,#906Ins
27 Title Flasher Flasher Blu-Orn J122-3 022 #906 Ins (2)
28 Professor Flasher Flasher Blu-Yel J122-4 020 #906 Ins
General illumination Circuits
01 Left Insert String 1 G.I. Wht-Brn J121-7 018 #555
02 Playfield Bottom String 2 G.I. Wht-Org J120-8 010 #555
03 Playfield Middle String 3 G.I. Wht-Yel J120-9 014 #555
04 Right Insert String 4 G.I. Wht-Grn J121-11 016 #555
05 Playfield Top String 5 G.I. Wht-Vio J120-11 012 #555
Lower Right Flipper Blu-Yel J109-7 FL-11630
Lower Left Flipper Gry-Yel J109-5 FL-11630
Midway Manufacturing Company reserves the rights to make modifications and improvements to its products.
The specifications and parts identified in this manual are subject to change without notice.
