return the Latch Lever toward the right, and close the coin door.
Carefully
slide the glass downward,
until it clears the grooves of the Left and Right Side Moldings. Lift the glass up and away from the
game, storing it carefully to avoid breakage.
8. Place a level or an inclinometer on the playfield surface. Adjust the leg levelers for proper playfield
level (side-to-side)
arul
playfield pitch angle (incline) of approximately 6-7 degrees. NOTE: It is
recommended that these measurements be made ON the playfield, not the cabinet nor the playfield
cover glass. Tighten the nut on each leg leveler shaft to maintain this setting, as shown in Figure 3.
I
,
,
-
,
<CAUTHON
Playfield pitch angle adjustments can affect the operation of the plumb bob tilt, inside the cabinet. The
plumb bob weight is among the parts in the cash box; the operator should install the weight and adjust
this tilt mechanism for proper operation, after completion of the desired playfield pitch angle setting.
9. Move the game into the desired location; recheck the level and pitch angle of the playfield.
r
"
,
'
,
10. Verify that the
required number
of balls are installed in the game.
GILUGAN'S ISLAND
uses 2
balls.
~ i
11. Install playfield mylars if desired.
.IL__
NOTE:
The Gilligan's Island Hardcoat playfield does not require a protective mylar. However,
playfield mylars can be purchased thru your local Bally Distributor. Specify part number 03-7960-
20003-1 for full playfield mylar and 03-7960-20003-2for jet bumper area mylar.
F -
i i ' -
12. Clean and reinstall the playfield cover glass, reversing the procedure of step 7. Prepare the game
for player operation.
GILLIGAN'S ISLAND 1-6
,
:'"
