A-13752
•
Jaw Drive Assembly
A-13941
Item Part No.
Description
1 01·9686-L
Bracket Jaw Drive Assy.
2 A-13751
Bracket Assembly
3 A-13997
Jaw Motor Assembly
4 03-8471
Gear
5 03-8470
Sector
6 4004-01003-03 Mach. Screw, #4-40 x
3116
7 4008-01017-06 Mach. Screw, #8-32 x 3/8
Eject Assembly
•
Item Part NUmber
Description
1 A-13942
Bracket Assembly
2 AE-26-1500
Coil Assembly
3 03-7067
Coil Tubing
4 10-135
Solenoid Spring
5 23-6420
Rubber Grommet
6 01-9784
Coil Bracket
7 A-13270
Bell Armature Assy.
8 4408-01119-00
Nut, #8-32 ESN
•
Jaw Drive Assembly
Eject Assembly
