CPU Assembly
2-4
A-12742-50003 WPC CPU Board
•
Item Part Number
Ckt Designator
Description
5010-09034.{)0
R14-R22, R27-R42, R86,
Resistor, 10Kn,
1/4w, 5%
R90, R94, R98
2 5010-09085'{)0
Rl,R2,R4,R93,R96,R97
Resistor, 1.5Kn,
1/4w, 5%
3 5010-09314-00
R52, R54, R56, R58, R60,
Resistor, 1.2Kn,
1/4w, 5%
R62, R64, R66, R75-R82
4 5010-09358'{)0
R3, R43-R51, R53, R55, R57,
Resistor, lKn,
1/4w, 5%
R59, R61, R63, R65, R67-R74,
R84
5 5010-09416'{)0
R5-R8, R12, R13, R87-R89
Resistor, 4700,
1/4w, 5%
6 5010-09534'{)0
W2, W4, W7
Resistor, 00
7 5010-10258-00
R95,R99
Resistor, .011lfdO,
1/4w, 5%
8 501 0-1 0989'{)0
R92
Resistor, 470KO,
1/4w, 5%
9 5010-12104.{)0
R91
Resistor, 22J.1fd,
1/4w, 5%
10 5019-09362'{)0
SiP 1
SIP, 9R, 10-pin, 4.7Kn, 5%
11 5040-08986-00
C31
Capacitor, l00llfd, lOY (±20%)
12 5043.{)8980-OO
B
Capacitor, .011lfd, 5OY, (+80, -20%)
13 5043.{)9030'{)0
C27
Capacitor, 0.047flfd, 50Y (±20%)
14 5043-09065-00
C3 - C26
Capacitor, 470pfd, SOv (±20%)
15 5043-{)9491-OO
C2, C29, C30, C34
Capacitor, 22pfd, lKV, (±10%)
16 5043.{)9492-{)0
C28
Capacitor, l00pfd, SOv, (±10%)
17 5043.{)9845-{)0
C32, C33
Capacitor, lKP, SOv, (±20%)
18 5070-08919-00
02 - 018
Diode, lN4148, 150MA
19 5070-09266-{)0
01,025
Diode, lN5817, 1.0A.
20
5160-10269-00
Ql
Transistor, 2N3904, NPN
21
5162-12422-{)0
U20
IC, ULN, 2803A
22
5281-{)9308-{)0
U3
IC, 74LS245, Octal Bus Tmcv
•
23
5281-{)9486-{)0
U14
IC, 74LS374, 80
FIF
24
5281-{)9851-{)0
U5
iC, 74LS14, SMTfTRG
25
5281-{)9867-00
Ul,U2,U7
IC, Octal Buffer, 74LS244
26
5281-10182-00
uu,
U12, U13, U15
IC, 74LS240 Driver
27
5284-12651-00
U21
iC,4584
28
5340-12278-00
U8
SlRAM 2064
29
5370-12272-00
U16 - U19
IC, LM339, Quad. Comp
30
5370-12687-00
Ul0
MC, 34064 Reset Chip
31
5520-10438-00
X2
Crystal, 8.0MHz.
32
5520-12084-00
Xl
Crystal 32.768 KHz
33
5551-09822-00
Ll
ILN, 4.7 UH 3A
34
5671-{)9019-oo
019 - 021
DSPLLED RED
35
5700-08985-00
U4
Socket, IC 40P, .6"
.'_
36
5700-12088-00
U6
Socket, IC 32P, .6"
37
5700-12424-{)0
U9
Socket, 84 Pin PLCC
38
5764-·12431-{)0
PC Board
39
5791-108SO.{)Q
J201,J204
Connector, 26-pin Header Str Sq.
40
5791-10862-{)7
J210
Connector, 7-pin Header Str Sq.
41
5791-12461-08
J212
Connector, 8-pin Header Str Sq.
42
5791-12461-09
J206 - J209
Connector,
9-pin Header Sq. pin
43
5791-12461-12
J205
Connector, 12-pin Header Sq. pin
44
5791-12516-00
J202,J211
34 Hen 2x17 STR
45
5881-{)9021'{)0
Bl- B3
Battery Holder'
M"
46
5048-11033-00
CSO
Capacitor, O.022flf, 10v
47
16-8850-319
PCB Label
48
A-5343-S0003-1
U6
Game F!_ROMAssembly
49
5410-12426.{)Q
U9
WPC-89 ASIC.
50
5400-10320-00
U4
IC MPU 68B09E
51
5880-09022-00
Bl - B3
Battery, Alkaline, 1.5v
("M")
•
