T.II DisplayTest
Once the test name is shown under the Test Menu, press the Enter button. This test allows you to
cycle through all of the display circuits. Each segment and digit should light in its tum. If a
segment or digit never lights, or stays lit all the time, the system has detected a problem. There are
two modes for testing the displays, Run and Stop.
Run - Press the Enter button when the Display Test is shown. The test cycles through several
phases automatically. Each phase is designed to test either an entire digit or a specific
segment.
Stop - Press the Enter button at any time during the Run portion ofthe Display Test and the test
stops. Once the test stops use the Up or Downbuttons to cycle through the test manually.
Press the Enter button again to resume the running test automatically.
Press the Escape button to return to the Test Menu. Press the Up button to advance to the next test, the
Rudy Test.
T.12 RudyTest
Once the test name is shown under the Test Menu, press the Enter button. This test has three modes
of operation and allows you to test aU of the solenoids that operate Rudy. Each solenoid should
operate in it's tum. If more then one turns On at a time, or stays On, or if nothing turns On during
the Run or Repeat test the system has detected a problem. Press the Up or Down button to select the
solenoid to be tested.
Repeat -
This test allows you to pulse a single solenoid. Press the Up or Down button to cycle
through the solenoids one at a time. The same solenoid pulses until you press the Up
or Downbutton to move to the next one. Either press the Escape button to return to the
Test Menu, or press the Enter button to move to the next test mode.
Stop
Press the Enter button during the Repeat test and the Rudy Test stops. There should
not be any solenoids activated at this point. Either press the Escape button to return
to the Test Menu, or press the Enter button to move to the next test mode.
Run
This test allow you to automatically cycle through the solenoids that operate Rudy.
Press the Enter button during the Stop test mode. The displays show you the name of
the solenoid being activated.
The last item in the Rudy Test is the Run Mouth Test. This test opens and closes the mouth. Press
the Enter button to activate.
Press the Escape button to return to the Test Menu. Press the Up button to advance to the next test, the
Trap Door Test.
1
,.
FUNHOUSE 1-33
